Configuring WAN Connections
Connection profiles
1-22 Preliminary January 30, 1998 Pipeline User’s Guide
>BACP=Yes
Dyn Alg=Quadratic
Sec History=15
Add Pers=5
Sub Pers=10
2
Open Ethernet > Connection > any profile.
3
Set the Encaps Option to MP.
For example:
Encaps=MP
4
Open the Encaps Options submenu of the same profile and set BACP to Yes.
For example:
Encaps options...
Send Auth=PAP
Send PW=*********
Aux Send PW=N/A
Recv PW=N/A
Base Ch Count=1
Min Ch Count=1
Max Ch Count=2
MRU=1524
LQM=No
LQM Min=600
LQM Max=600
Link Comp=Stac
VJ Comp=Yes
>BACP=Yes
Dyn Alg=Quadratic
Sec History=15
Add Pers=5
Sub Pers=10
Target Util=70
Note:
The Idle Percent parameter does not appear in the Encaps Options
menu when Encaps is set to MP, as it does not apply to MP or BACP.
