LM61 User Manual LM61 User Manual 1
LM61 User Manual Index 1. About this Manual............................................................................ 3 2. Product Overview ............................................................................ 3 3. Configuring the model .................................................................... 3 3.1 Login ............................................................................................................... 3 3.2 Dashboard ...................................................
LM61 User Manual 1. About this Manual The content of this User Manual has been made as accurate as possible. However, due to continual product improvements, specifications and other information are subject to change without notice. 2. Product Overview LM61 supports LTE Band 4/13 (Subject to the configuration of LTE module) and it supports popular operating systems like Windows, Linux and Mac. 3.
LM61 User Manual The bars in the middle indicate the received signal level, data connection status, USIM status shown as below picture: LTE signal level Data connection Icon, when model connect to network, the icon is on, otherwise, it is grey USIM card status. If model work without USIM card. The USIM card icon change to Reboot key. It is used to reboot the device Log out key.
LM61 User Manual 3.3 4G 3.3.1 Setting Connection Mode: bridge and router, default mode is bridge Connection Type: Auto and manual, default type is auto Figure 3-3-1-1 Setting 3.3.2 APN Settings Figure 3-3-2-1 APN Settings The default APN type is IPV4 and APN is NULL, if you want to configure the LTE APN, you should choose the manual mode, and then you can configure the APN settings 3.3.3 PIN Management From this page, you can see the USIM card status and PIN status.
LM61 User Manual Figure 3-3-3-1 PIN Management The default PIN status is disabled; you can input the correct PIN to enable the PIN function. The maximum PIN attempts are 3; otherwise you must enter PUK to reset the PIN code. The USIM will be invalid after the unsuccessful attempts for 10 times. PIN Management: Enter the correct PIN to enable or disable the PIN function, PIN code should be 4 to 8 digits; 3.3.4 LAN Settings From this page, you can set all settings for the internal LAN.
LM61 User Manual IP Address Enter the IP address of your router (factory default: 192.168.0.1). Subnet Mask ‐ An address code that determines the size of the network. Normally use 255.255.255.0 as the subnet mask. DHCP ‐ Enable or Disable the DHCP server. If you disable the Server, Client cannot get valid IP address from model automatically.
LM61 User Manual Figure 3-4-1 Status 3.4.1 WAN Status From the WAN Status, WAN IP Address, WAN Primary DNS and WAN Secondary DNS information can be displayed Figure 3-4-1-1 WAN Status 3.4.2 LAN Status From this page, you can see the LAN Status such as IP, local net mask, DHCP server and MAC address. Figure 3-4-2-1 WiFi LAN Status 3.4.3 4G Status Clicking on the “4G Status”, you can see the LTE information such as Connection Status, USIM Status, IMEI, IMSI, RSSI, and SINR.
LM61 User Manual Figure 3-4-3-1 LTE Status 3.4.4 Software Status Software version and the DTB version can be displayed. Figure 3-4-4-1 Software 3.5 System On this page you can set System Menu: Password and backup & restore.
LM61 User Manual Figure 3-5-1 System 3.5.1 Password The default password is admin, you can enter 1~32 characters for 2 times as your new password. Then you would logout automatically and you should login to the system by the new password. Figure 3-5-1-1 Password 3.5.2 Backup & Restore Clicking the “Export” button, the current settings will be saved as a data file to the local PC. You can import the device configuration from the files that you saved. You can restore and reboot the device.
LM61 User Manual Figure 3-5-2-1 Backup & Restore Federal Communications Commission (FCC) Statement 15.21 You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. 15.105(b) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules.
LM61 User Manual FCC RF Radiation Exposure Statement: To comply with the FCC RF exposure compliance requirements, this device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
