Quick Installation Guide
Quick Installation GuideQuick Installation Guide
Quick Installation Guide
EAI2001S Enterprise Access Point ENGLISH
Askey EAI2001S supports web-based configuration. When hardware installation is complete, EAI2001S can
be configured through a PC by using a web browser such as Mozilla Firefox 2.0 or Internet Explorer version
6.0 and above.
The default values of LAN IP address and subnet mask of EAI2001S are:
IP Address: 192.168.1.1
Subnet Mask: 255.255.255.0
Steps:
1. To access the Web Management Interface, connect the administrator PC to the Uplink port of EAI2001S
via an Ethernet cable. Then, set a static IP address on the same subnet mask as EAI2001S in TCP/IP of
your PC, such as the following example:
IP Address: 192.168.1.100
Subnet Mask: 255.255.255.0
2. Launch the web browser on your PC by entering the IP address of EAI2001S (http://192.168.1.1) in the
address field, and then press Enter.
Example of entering EAI2001S's default IP Address via a web browser
3. The following Admin Login Page will appear. Enter “admin” for both the Username and Password fields,
and then click Login.
Administrator Login Page
Getting Started
