INSTALLATION INSTRUCTIONS TD75 Carefully read the instructions for use before using the dryer.
Dear Customer, Read these instructions carefully and completely before you install the machine. The installation should be carried out by a qualified person who is familiar with all local codes and ordinances for electrical and plumbing connections. See also the general Safety Instructions in the Use & Care Guide. Cosmetic damage must be reported to the ASKO dealer within five days from the date of purchase. As soon as you unpack the machine, thoroughly check it for cosmetic damage.
Free-standing appliance The dryer may be placed adjacent to a washing machine. If the friction between the dryer feet and the floor is not sufficient, the dryer may move during operation. To prevent the dryer from sliding around, use a non-slip support or pad. Stacking on top of a washing machine To stack the dryer on top of a washing machine, use the extra vacuum feet and the tipping guard (A+B), supplied in the cardboard box in the dryer drum.
How to stack a dryer onto the washing machine (ASKO): There is a cardboard box in the dryer drum, containing the vacuum feet and the tipping guard. 1 A B The tipping guard consists of two metal parts (A + B). Use two screws to attach the A part to the back of the dryer. 1 2 Undo the screw on the back side of the washing machine. 3 Use the screw to attach the tipping guard (B part) to the back of the washing machine. 4 Level the washing machine so that it is stable. 1.
CHANGING THE DOOR OPENING DIRECTION To change the direction of door opening, proceed as follows. 1 Open the door fully. 2 Undo the screws and remove the door. 3 Use the screwdriver to remove the door lock cover and undo the screw on the door lock. 4 Push the door lock upwards and remove it. Move it to the other side and push it downwards. 5 Fasten the screw on the door lock. Replace the door lock cover. Customer Care Center, 1-800-898-1879, www.askousa.
Undo the door hinge assembly (left) and the door latch assembly (right), switch their positions, and replace the screws (door hinge assembly to the righthand side, door latch assembly to the left-hand side). 6 Use the screwdriver to remove the plastic part more easily. 7 Undo the door ring and remove it temporarily. Rotate the door glass cover by 90° so that the sign indicating the opening of the door is on the other side.
BUILT-IN not possible to install the dryer anywhere else, then the refrigeration appliance must be sealed off from the dryer. Install in a closet 77 30 -1/ 0 m 3" m ASKO's front panel controls make it possible to install the washers and dryers in a closet. Make sure there is a ½” (12 mm) minimum clearance between units and cabinet or wall and a 1" (25 mm) minimum clearance between the rear edge of the machine top panel and the cabinet or wall.
DRAINING THE CONDENSATE The moisture from the laundry is extracted in the condenser unit and accumulated in the condensate tank. Condensate tank has to be emptied regularly (see chapter "CLEANING AND MAINTENANCE"). Interruption of the drying cycle due to full condensate tank can be avoided by running the condensate discharge hose found at the back of the appliance directly into a drain.
ELECTRICAL INSTALLATION The receptacle on the rear of the machine is designed to accommodate ASKO washers ONLY (rated 208–240 V.) To use this receptacle, you must use the ready-fitted plug supplied with the washing machine or an equivalent. ASKO washers rated 208–240 V have two internal fuses of 15 A each. The machine should only be connected to a grounded wall socket. This appliance must be properly grounded. Refer to the “Important Safety Instructions” for grounding instructions.
1. Turn the power off at the breaker or fuse box. 2. Remove terminal block cover. 3. Use the strain relief attached below the terminal block opening. 4. Loosen or remove center terminal block screw. 4 5 6 5. Connect ground (center) wire of power supply cord to the center, silver-colored terminal screw. Tighten screw. 6. Connect the other wires to outer screws. 7. Tighten the strain relief screws. 8. Replace terminal box cover on back of dryer. 9. Plug dryer into wall receptacle. 10.
Customer Care Center, 1-800-898-1879, www.askousa.
