INSTALLATION INSTRUCTIONS WM85 Carefully read the instructions for use before using the washing machine.
Dear Customer, Read these instructions carefully and completely before you install the machine. The installation should be carried out by a qualified person who is familiar with all local codes and ordinances for electrical and plumbing connections. See also the general Safety Instructions in the Use & Care Guide. Cosmetic damage must be reported to the ASKO dealer within five days from the date of purchase. As soon as you unpack the machine, thoroughly check it for cosmetic damage.
INSTALLATION Read these instructions carefully and completely before you install the machine. The installation should be carried out by a qualified person who is familiar with all local codes and ordinances for electrical and plumbing connections. Cosmetic damage must be reported to your dealer within five days from the date of purchase. After unpacking the washer, thoroughly check the unit for cosmetic damage. ADJUSTING THE FEET Place the washing machine so that it is stable.
See the "Settings" chapter for information on how to switch between "Hot water On" and "Hot water Off". INSTALLING THE DRAIN HOSE Drain hose can also be connected directly to the washbasin drain via a siphon. In this case, the hose, too, should be 24" to 36" mm above the floor. Internal hose diameter should be at least 18 mm. See figure. At least 18 mm If the hose is extended, the internal diameter of the coupling must not be less than ½".
ELECTRICAL CONNECTIONS The machine is delivered ready-fitted with a plug and is intended for connection to an ASKO Dryer, which is equipped with a matching receptacle. The plug supplied with the washer can only be used with an ASKO Dryer. If the washer is used separately or with another dryer, it must be on a separate 208-240 V single-phase circuit. If the machine is to be used in a wet area, the supply must be protected by a residual current device.
Clearances around the washing machine min. 50 mm Built-in installation ASKO washers can be installed beneath a cabinet or worktop with a height of 34” to 35” (900 to 950 mm) or in a closet. There must be a gap of about ½” (12 mm) all around the machine, including between the rear edge of the machine’s top panel and the back wall. The opening width must be at least 24½” (622 mm). Space must also be available for the fi ll and drain hoses. See the illustration below for measurements and positions.
NOTES Customer Care Center, 1-800-898-1879, www.askousa.
