PCIE Frequency (MHz)
Use this option to adjust PCIE frequency. The default value is [100].
Boot Failure Guard
Enable or disable the feature of Boot Failure Guard.
CPU/LDT Spread Spectrum
This feature will be set to [0.75% Hershey] as default. Configuration
options: [Disabled], [0.5% Hershey], [0.75% Hershey], [0.5% Triangular],
and [0.75% Triangular].
PCIE Spread Spectrum
This feature will be set to [Enabled] as default. Configuration
options: [Disabled], and [Enabled].
SATA Spread Spectrum
This feature will be set to [Enabled] as default. Configuration
options: [Disabled], and [Enabled].
Cool ‘n’ Quiet
Use this item to enable or disable AMD’s Cool ‘n’ Quiet
TM
technology.
Processor Maximum Multiplier
It will display Processor Maximum Multiplier for reference.
Processor Maximum Voltage
It will display Processor Maximum Voltage for reference.
Multiplier/Voltage Change
This item is set to [Auto] by default. If it is set to [Manual], you may adjust the
value of Processor Multiplier and Processor Voltage. However, it is recom-
mended to keep the default value for system stability.
BIOS SETUP UTILITY
BIOS SETUP UTILITY
CPU Configuration
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2003, American Megatrends, Inc.
Advanced
Select Screen
Select Item
+- Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
CPU Frequency (MHz)
PCIE Frequency (MHz)
Overclock Mode
[200]
[100]
[Auto]
CPU/LDT Spread Spectrum
PCIE
SATA
Cool'n'Quiet
Spread Spectrum
Spread Spectrum
[0.75% Hershey]
[Enabled]
[Enabled]
[Enabled]
Processor Maximum Multiplier
Processor Maximum Voltage
Memory Clock
Flexibility Option
CAS Latency
TRAS
[Auto]
[Auto]
[Disabled]
[Auto]
x11
1.550 V
Boot Failure Guard
[Enabled]
Multiplier/Voltage Change
[Manual]
If AUTO, multiplier and
voltage will be left at the
rated frequency/voltage. If
Manual,
will be set based
on User Selection in Setup.
multiplier and
voltage
BIOS SETUP UTILITY
Processor Multiplier
Processor Voltage
[x8]
[1.500V]
Processor Multiplier
This item will show when “Multiplier/Voltage Change” is set to [Manual];
otherwise, it will be hidden. You may set the value from [x8] up to [x25] but
no higher than the value of “Processor Maximum Multiplier”. For example, if
the value of “Processor Maximum Multiplier” is [x11], the actual value of
multiplier will be [x11] even if you set this item to a value higher than [x11].
