ASUS Desktop PC BM6620(MD530), BM6820, and BP6320(SD530) BM6620(MD530) BM6820 BP6320(SD530) User Manual
E7364 Second Edition April 2012 Copyright © 2012 ASUSTeK Computer Inc. All Rights Reserved. No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK Computer Inc. (“ASUS”).
Contents Notices ........................................................................................................... 5 Safety information........................................................................................... 7 Conventions used in this guide....................................................................... 8 Where to find more information...................................................................... 8 Package contents..................................................
Contents Chapter 7: Troubleshooting Troubleshooting............................................................................................ 63 ASUS contact information.............................................................................
Notices ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components, as well as the packaging materials. Please go to http://csr.asus.com/english/Takeback.htm for the detailed recycling information in different regions.
RF exposure warning This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provide with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
Safety information Disconnect the AC power and peripherals before cleaning. Wipe the Desktop PC using a clean cellulose sponge or chamois cloth dampened with solution of nonabrasive detergent and a few drops of warm water then remove any extra moisture with a dry cloth. • DO NOT place on uneven or unstable work surfaces. Seek servicing if the casing has been damaged. • DO NOT expose to dirty or dusty environments. DO NOT operate during a gas leak.
Conventions used in this guide To ensure that you perform certain tasks properly, take note of the following symbols used throughout this manual. DANGER/WARNING: Information ������������������������������������������ to prevent injury to yourself when trying to complete a task. CAUTION: Information ������������������������������������������������ to prevent damage to the components when trying to complete a task. IMPORTANT: Instructions that you MUST follow to complete a task.
Package contents ASUS Desktop PC Keyboard x1 Mouse x1 Power cord x1 Support DVD x1 (Optional) Recovery DVD x1 (Optional) Installation Guide Nero 9 burning software Installation Guide x1 Warranty card x1 DVD x1 (Optional) • If any of the above items is damaged or missing, contact your retailer. • The illustrated items above are for reference only. Actual product specifications may vary with different models.
Chapter 1 Getting started Welcome! Thank you for purchasing the ASUS Desktop PC! The ASUS Desktop PC provides cutting-edge performance, uncompromised reliability, and user-centric utilities. All these values are encapsulated in a stunningly futuristic and stylish system casing. Read the ASUS Warranty Card before setting up your ASUS Desktop PC. Getting to know your computer Illustrations are for reference only. The ports and their locations, and the chassis color vary with different models.
ENGLISH Front panel 1 2 3 9 4 8 5 7 6 BM6620(MD530) 12 1. 2 x 5.25 inch optical disk drive bays. The 5.25 inch optical disk drive bays are for 5.25 inch DVD-ROM / CD-RW / DVD-RW devices.�� 2. Microphone port (pink). This port connects to a microphone. 3. Headphone port (lime). This port connects to a headphone or speaker. 4. USB 2.0 ports. These Universal Serial Bus 2.0 (USB 2.0) ports connect to USB 2.0 devices such as a mouse, printer, scanner, camera, PDA, and others. 5. Reset button.
ENGLISH 1 2 3 2 4 8 5 7 6 BM6820 1. Optical disk drive. The optical disk drive supports DVD-RW / CD-RW / DVD-ROM.�� 2. Optical disk drive eject button. Press this button to eject the optical disk drive tray. 3. Optical disk drive bay (empty). You may install an additional optical disk drive in this bay.�� 4. HDD LED. This LED lights up when the hard disk drive operates. 5. Power button. Press this button to turn on your computer. 6. Microphone. This port connects to a microphone. 7.
ENGLISH 1 2 3 7 6 5 4 BP6320(SD530) 14 1. Optical disk drive eject button. Press this button to eject the optical disk drive tray. 2. Optical disk drive. The optical disk drive supports DVD-RW / CD-RW / DVD-ROM.�� 3. HDD LED. This LED lights up when the hard disk drive operates. 4. Microphone. This port connects to a microphone. 5. Headphone port. This port connects to a headphone or speaker. 6. USB 2.0 ports. These Universal Serial Bus 2.0 (USB 2.0) ports connect to USB 2.
Rear panel ENGLISH 1 16 2 3 4 5 8 9 10 6 17 7 16 15 5 14 11 12 13 BM6620(MD530) 1. ������������������ Power connector. Plug the power cord to this connector. 2. Voltage selector. Use this switch to select the appropriate system input voltage according to the voltage supply in your area. If the voltage supply in your area is 100127V, set the switch to 115V. If the voltage supply in your area is 200-240V, set the switch to 230V.
7. ��������������� USB 3.0 ports. These Universal Serial Bus 3.0 (USB 3.0) ports connect to USB 3.0 devices such as a mouse, printer, scanner, camera, PDA, and others. ENGLISH • DO NOT connect a keyboard / mouse to any USB 3.0 port when installing Windows® operating system. • Due to USB 3.0 controller limitation, USB 3.0 devices can only be used under Windows® OS environment and after the USB 3.0 driver installation. • USB 3.0 devices can only be used as data storage only.
16. ����������� Air vents. These vents allow air ventilation. ENGLISH DO NOT block the air vents on the chassis. Always provide proper ventilation for your computer. 17. ���������� VGA port. This port is for VGA-compatible devices such as a VGA monitor. 1 14 2 3 4 5 6 15 7 9 10 11 14 8 13 12 BM6820 1. Voltage selector. Use this switch to select the appropriate system input voltage according to the voltage supply in your area.
ENGLISH 4. PS/2 mouse port (green). This port is for a PS/2 mouse. 5. PS/2 keyboard port (purple). This port is for a PS/2 keyboard. 6. COM port. This port is for pointing devices or other serial devices. 7. ������������ DVI-D port. This port is for any DVI-D compatible device and is HDCP compliant allowing playback of HD DVD, Blu-ray, and other protected content. 8. ��������������� USB 2.0 ports. These Universal Serial Bus 2.0 (USB 2.0) ports connect to USB 2.
14. ����������� Air vents. These vents allow air ventilation. ENGLISH DO NOT block the air vents on the chassis. Always provide proper ventilation for your computer. 15. ���������� VGA port. This port is for VGA-compatible devices such as a VGA monitor. 1 2 3 14 4 5 13 11 6 7 8 9 12 10 11 BP6320(SD530) 1. PS/2 mouse port (green). This port is for a PS/2 mouse. 2. PS/2 keyboard port (purple). This port is for a PS/2 keyboard. 3. COM port.
6. ������������������������ Microphone port (pink). This port connects to a microphone. ENGLISH 7. ���������������������� Line Out port (lime). This port connects to a headphone or speaker. In a 4, 6, or 8-channel configuration, the function of this port becomes Front Speaker Out. 8. ��������������������������� Line In port (light blue). This port connects to a tape, CD, DVD player, or other audio sources.
Setting up your computer ENGLISH This section guides you through connecting the main hardware devices, such as the external monitor, keyboard, mouse, and power cord, to your computer. Using the onboard display output ports Connect your monitor to the onboard display output port. To connect an external monitor using the onboard display output ports: 1. Connect your monitor to the VGA port, DVI-D port, or display port of your computer. 2. Plug your monitor to a power source.
BM6820 ENGLISH BP6320(SD530) If your computer comes with an ASUS Graphics Card, the graphics card is set as the primary display device in the BIOS. Hence, connect your monitor to a display output port on the graphics card.
Connecting a USB keyboard and a USB mouse ENGLISH Connect a USB keyboard and a USB mouse to the USB ports on the rear panel of your computer.
BP6230/SD510 ENGLISH Connecting the power cord Connect one end of the power cord to the power connector on the rear panel of your computer and the other end to a power source.
ENGLISH BM6820 BP6320(SD530) ASUS BM6620(MD530), BM6820, and BP6320(SD530) 25
Turning your computer ON/OFF This section describes how to turn on/off your computer after setting up your computer. ENGLISH Turning your computer ON To turn your computer ON: 1. Turn your monitor ON. 2. Turn the power switch ON (for BM6630/MD510 and BM6330 only). 3. Press the power button on your computer. Power button Power button BM6820 Power button BP6320(SD530) 3. Wait until the operating system loads automatically. Turning your computer OFF To turn your computer OFF: 26 1.
ENGLISH Chapter 2 Using Windows® 7 Starting for the first time When you start your computer for the first time, a series of screens appear to guide you in configuring the basic settings of your Windows® 7 operating system. To start for the first time: 1. Turn your computer on. Wait for a few minutes until the Set Up Windows screen appears. 2. From dropdown list, select your language, then click Next. 3.
Using Windows® 7 desktop ENGLISH Click the Start icon > Help and Support to obtain more information about Windows® 7. Using the Start menu The Start menu gives you access to programs, utilities, and other useful items on your computer. It also provides you with more information about Windows 7 through its Help and Support feature. Launching items from the Start menu To launch items from the Start menu: 1. From the Windows® taskbar, click the Start icon . 2.
Pinning items on the jumplists ENGLISH When you right-click an icon on the taskbar, a jumplist launches to provide you with quickaccess to the program’s or item’s related links.You may pin items on the jumplist such as favorite websites, often-visited folders or drives, or recently played media files. To pin items to the jumplist: 1. From the taskbar, right-click an icon. 2. From the jumplist, right-click the item that you want to pin, then select Pin to this list.
Using the notification area ENGLISH By default, the notification area shows these three icons: Action Center notification Click this icon to display all the alert messages/notifications and launch the Windows® Action Center. Network connection This icon displays the connection status and signal strength of the wired or wireless network connection. Volume Click this icon to adjust the volume.
Exploring files and folders 1. Launch Windows® Explorer. 2. From the navigation or view pane, browse for the location of your data. 3. From the breadcrumb bar, click the arrow to display the contents of the drive or folder. ENGLISH To explore files and folders: Customizing the file/folder view To customize the file/folder view: 1. Launch Windows Explorer. 2. From the navigation pane, select the location of your data. 3. From the toolbar, click the View icon 4.
ENGLISH Adding a new folder To add a new folder: 1. Launch Windows Explorer. 2. From the toolbar, click New folder. 3. Key in a name for the new folder. You may also right-click anywhere on the View pane, click New > Folder. Backing up your files Setting up a backup To set up a backup: > All Programs > Maintenance > Backup and Restore. 1. Click 2. Click Set up backup. Click Next. 3. Select your backup destination. Click Next. 4.
ENGLISH Protecting your computer Using Windows® 7 Action Center Windows® 7 Action Center provides you with alert notifications, security information, system maintenance information, and the option to automatically troubleshoot and fix some common computer problems. You may customize the notifications. For more details, refer to the previous section Customizing icons and notifications in this chapter. Launching Windows® 7 Action Center To launch Windows® 7 Action Center: 1.
ENGLISH Setting up a user’s password To set up a user’s password: 1. Select the user that you would like to set a password. 2. Select Create a password. 3. Key in a password and confirm it. Key in your password’s hint. 4. When done, click Create password. Activating the anti-virus software Trend Micro Internet Security is pre-installed on your computer. It is a third-party anti-virus software protecting your computer from virus. It is purchased separately.
Chapter 3 ENGLISH Connecting devices to your computer Connecting a USB storage device This desktop PC provides USB 2.0/1.1 ports on both the front and rear panels. The USB ports allow you to connect USB devices such as storage devices. To connect a USB storage device: • Insert the USB storage device to your computer.
Rear panel ENGLISH BM6820 BP6320(SD530) 36 Chapter 3: Connecting devices to your computer
Connecting microphone and speakers ENGLISH This desktop PC comes with microphone ports and speaker ports on both the front and rear panels. The audio I/O ports located on the rear panel allow you to connect 2-channel, 4-channel, 6-channel, and 8-channel stereo speakers.
ENGLISH BP6320(SD530) Connecting 2-channel Speakers 38 Chapter 3: Connecting devices to your computer
ENGLISH Connecting 4-channel Speakers Connecting 6-channel Speakers ASUS BM6620(MD530), BM6820, and BP6320(SD530) 39
Connecting 8-channel Speakers ENGLISH 40 Chapter 3: Connecting devices to your computer
ENGLISH Chapter 4 Using your computer Proper posture when using your Desktop PC When using your Desktop PC, maintaining the proper posture is necessary to prevent strain to your wrists, hands, and other joints or muscles. This section provides you with tips on avoiding physical discomfort and possible injury while using and fully enjoying your Desktop PC.
Using the optical drive (on selected models only) ENGLISH 2 1 3 Inserting an optical disc To insert an optical disc: 1. While your system is on, press the eject button below the drive bay cover to open the tray. 2. Place the disc to the optical drive with the label side facing up. 3. Push the tray to close it. 4. Select a program from the AutoPlay window to access your files.
ENGLISH Chapter 5 Connecting to the Internet Wired connection Use an RJ-45 cable to connect your computer to a DSL/cable modem or a local area network (LAN). Connecting via a DSL/cable modem To connect via a DSL/cable modem: 1. Set up your DSL/cable modem. Refer to the documentation that came with your DSL/cable modem. 2. Connect one end of an RJ-45 cable to the LAN (RJ-45) port on the rear panel of your computer and the other end to a DSL/cable modem.
BM6820 ENGLISH Modem RJ-45 cable BP6320(SD530) Modem RJ-45 cable 3. Turn on the DSL/cable modem and your computer. 4. Configure the necessary Internet connection settings. Contact your Internet Service Provider (ISP) for details or assistance in setting up your Internet connection.
Connecting via a local area network (LAN) To connect via a LAN: Connect one end of an RJ-45 cable to the LAN (RJ-45) port on the rear panel of your computer and the other end to your LAN. ENGLISH 1.
BP6320(SD530) ENGLISH RJ-45 cable 2. Turn on your computer. 3. Configure the necessary Internet connection settings. LAN Contact your network administrator for details or assistance in setting up your Internet connection.
ENGLISH Chapter 6 Using the utilities The Support DVD and Recovery DVD may not be included in the package. You may use the Recovery Partition feature to create the Support DVD and Recovery DVD. ASUS AI Suite II ASUS AI Suite II is an all-in-one interface that integrates several ASUS utilities and allows users to launch and operate these utilities simultaneously. Installing AI Suite II To install AI Suite II: 1. Place the support DVD in the optical drive.
The Tool menu ENGLISH The Tool menu includes the EPU, Probe II, and Sensor Recorder panels. Launching EPU EPU is an energy-efficient tool that provides you with a total power-saving solution. It detects the current loading and intelligently adjusts the power usage in real-time. When you select the Auto mode, the system changes modes automatically according to the current system status.
Launching and configuring Probe II ENGLISH Probe II is a utility that monitors the computer’s vital components, and detects and alerts you of any problem with these components. Probe II senses fan rotations, CPU temperature, and system voltages, among others. With this utility, you are assured that your computer is always at a healthy operating condition. To launch Probe II: Click� Tool > Probe II on the AI Suite II main menu bar.
Launching and configuring Sensor Recorder ENGLISH Sensor Recorder allows you to monitor the changes in the system voltage, temperature, and fan speed, as well as recording the changes. To launch Sensor Recorder: Click Tool > Sensor Recorder on the AI Suite II main menu bar. To configure Sensor Recorder: • Click the Voltage/Temperature/Fan Speed tabs and select the sensors that you want to monitor. • The History Record tab allows you to record the changes in the sensors that you enable.
The Monitor menu ENGLISH The Monitor menu includes the Sensor and CPU Frequency panels. Launching Sensor The Sensor panel ������������������������������������������������������������������������ displays the current value of a system sensor such as fan rotation, CPU temperature, and voltages. To launch Sensor: Click Monitor > Sensor on the AI Suite II main menu bar.
ENGLISH Updating the BIOS through a BIOS file To update the BIOS through a BIOS file: 1. From the ASUS Update screen, select Update BIOS from file, then click Next. 2. Locate the BIOS file from the Open window, click Open, and click Next. 3. Click Yes if you want to change the boot logo, which is the image appearing on screen during the Power‑On Self-Tests (POST).������������������ Otherwise, click No. 4. Follow the onscreen instructions to complete the update process.
ASUS AI Manager ENGLISH ASUS AI Manager is a utility which gives you quick and easy access to frequently-used applications. Installing AI Manager To install AI Manager: 1. Place the support DVD in the optical drive. If Autorun is enabled, the Drivers installation wizard appears. If Autorun is disabled, double-click the setup.exe file from the ASUS AI Manager folder in the support DVD. 2. Click the Utilities tab, then click ASUS AI Manager. 3.
AI Manager quick bar ENGLISH The AI Manager quick bar saves the desktop space and allows you to launch the ASUS utilities or display system information easily. Click any of the Main, My Favorites, Support or Information tab to display the menu’s contents. Exit button Switch to main Window Add to ToolBar Click to extend or restore Main Support My Favorites Information Click the Maximize/restore button to switch between full window and quick bar.
AI Booting 1. 2. ENGLISH AI Booting allows you to specify the boot device priority sequence. To specify the boot sequence: Select a device, then click the left/right button to specify the boot sequence. When done, press Apply. My Favorites My Favorites allows you to add applications that you frequently use, saving you from searching for the applications throughout your computer. To add an application: 1. Click Add, then locate the application you want to add to My Favorites. 2.
ASUS Secure Delete ENGLISH ASUS Secure Delete makes deleted files completely irrecoverable via a simple drag-anddrop interface, thus protecting your data security. To use ASUS Secure Delete: 1. 2. 56 Do either of the following to launch ASUS Secure Delete: • Click the ASUS Secure Delete shortcut on the Windows® desktop. • Click Start > All Programs > ASUS > ASUS Secure Delete. Do any of the following to add files to the deletion box: • Drag and drop the files to the deletion box.
Click Clear, and then click OK on the confirmation message to permanently delete all the files listed in the deletion box and the recycle bin (if selected in step 4). ENGLISH 5. Recovering your system Using the system recovery partition The system recovery partition quickly restores your Desktop PC’s software to its original working state.
Using the Recovery DVD (on selected models) ENGLISH Remove the external hard disk drive before performing system recovery on your Desktop PC. According to Microsoft, you may lose important data because of setting up Windows on the wrong disk drive or formatting the incorrect drive partition. To use the Recovery DVD: 1. Insert the Recovery DVD into the optical drive. Your Desktop PC needs to be powered ON. 2.
ASUS Webstorage ENGLISH ASUS webstorage is designed to help you retrieve your data to your notebooks, smartphones or tablets wherever there is internet connection. Installing webstorage To install webstorage: Place the support DVD in the optical drive. Double-click the setup.exe file from the ASUS WebStorage folder in the Software folder in the support DVD. Launching Webstorage To launch the WebStorage from the Windows® desktop, click Start > All Programs > ASUS > Webstorage.
Calendar ENGLISH ASUS WebStorage automatically syncs the most updated calendar events to all personal computers so that you know the exact events no matter which PC is in use. BookmarkSyncer The convenient BookmarkSyncer keeps our browser preference and bookmark to the cloud automatically synchronized in multiple computer. MobileApp ASUS WebStorage mobile applications sync your files between multiple devices.
ASUS Easy Update 1. From the Windows ® notification area, right-click the ASUS Easy Update icon. 2. Select Schedule to set how often you want to update your system. 3. Select Update to activate the update. 4. Click OK to display the items you can download. 5. Check the item(s) you want to download, and then click OK. ASUS BM6620(MD530), BM6820, and BP6320(SD530) ENGLISH ASUS Easy Update is a software tool that automatically detects the latest drivers and applications for your system.
ENGLISH 62 Chapter 6: Using the utilities
ENGLISH Chapter 7 Troubleshooting Troubleshooting This chapter presents some problems you might encounter and the possible solutions. ? ? My computer cannot be powered on and the power LED on the front panel does not light up • Check if your computer is properly connected. • Check if the wall outlet is functioning. • Check if the Power Supply Unit is switched on. Refer to the section Turning your computer ON/OFF in Chapter 1. My computer hangs.
? ENGLISH ? ? ? No display on the monitor. • Check if the monitor is powered on. • Ensure that your monitor is properly connected to the video output port on your computer. • If your computer comes with a discrete graphics card, ensure that you connect your monitor to a video output port on the discrete graphics card. • Check if any of the pins on the monitor video connector is bent. If you discover bent pins, replace the monitor video connector cable.
The picture on the HDTV is distorted. • It is caused by the different resolutions of your monitor and your HDTV. Adjust the screen resolution to fit your HDTV. To change the screen resolution: 1. ENGLISH ? Do any of the following to open the Screen Resolution setting screen: • Click > Control Panel > Appearance and Personalization > Display > Change display settings. • R ight click anywhere on your Windows desktop.
ENGLISH Power Problem No power (The power indicator is off) Possible Cause Action Incorrect power voltage • S et your computer’s power voltage switch to your area’s power requirements. • Adjust the voltage settings. Ensure that the power cord is unplugged from the power outlet. Your computer is not turned on. Press the power key on the front panel to ensure that your computer is turned on. Your computer’s power cord is not properly connected.
Problem Cannot access the Internet Possible Cause Action The LAN cable is not connected. Connect the LAN cable to your computer. LAN cable problems Ensure the LAN LED is on. If not, try another LAN cable. If it still does not work, contact the ASUS service center. Your computer is not properly connected to a router or hub. ENGLISH LAN Ensure that your computer is properly connected to a router or hub. Network settings Contact your Internet Service Provider (ISP) for the correct LAN settings.
ENGLISH System Problem System speed is too slow The system often hangs or freezes. 68 Possible Cause Action Too many programs are running. Close some of the programs. Computer virus attack • U se an anti-virus software to scan for viruses and repair your computer. • Reinstall the operating system. Hard disk drive failure • Send the damaged hard disk drive to ASUS Service Center for servicing. • Replace with a new hard disk drive.
Problem Too noisy right after turning on the computer. Computer is too noisy when in use. Possible Cause Action Your computer is booting up. It is normal. The fan runs on its full speed when the computer is powering on. The fan slows down after entering the OS. The BIOS settings have been changed. Restore the BIOS to its default settings. Old BIOS version Update the BIOS to the latest version. Visit the ASUS Support site at http://support.asus.com to download the latest BIOS versions.
ASUS contact information ASUSTeK COMPUTER INC. Address Telephone Fax E-mail Web site Technical Support Telephone Online support 15 Li-Te Road, Peitou, Taipei, Taiwan 11259 +886-2-2894-3447 +886-2-2890-7798 info@asus.com.tw www.asus.com.tw +86-21-38429911 support.asus.
