MB169C+ USB Type-C Monitor User Guide USB-C I DP ALTERNATE SUPPORT
Table of contents Notices.......................................................................................................... iii Safety information....................................................................................... iv Care & cleaning............................................................................................. v Takeback services....................................................................................... vi 1.1 Welcome!...................................
Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Safety information iv • Before setting up this USB Type-C monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose this USB Type-C monitor to rain or moisture. • Never try to open this USB Type-C monitor cabinet. • Before using this USB Type-C monitor, make sure all cables are correctly connected and the power cables are not damaged. If you detect any damage, contact your dealer immediately.
Care & cleaning • Cleaning. Turn your monitor off and unplug the power cord. Clean the monitor surface with a lint-free, non-abrasive cloth. Stubborn stains may be removed with a cloth dampened with mild cleaner. • Avoid using a cleaner containing alcohol or acetone. Use a cleaner intended for use with the LCD. Never spray cleaner directly on the screen, as it may drip inside the monitor and cause an electric shock.
Where to find more information Refer to the following sources for additional information and for product and software updates. 1. ASUS websites The ASUS websites worldwide provide updated information on ASUS hardware and software products. Refer to http://www.asus.com 2. Optional documentation Your product package may include optional documentation that may have been added by your dealer. These documents are not part of the standard package.
1.1 Welcome! Thank you for purchasing the ASUS® USB Type-C monitor! The latest ASUS USB Type-C monitor provides great portability and simplicity to your daily life, enhancing both of your viewing experience and style. 1.2 Package contents Check your package for the following items: USB Type-C monitor Quick Start Guide Warranty Card USB Type-C Cable Carrying Case/Stand • If any of the above items is damaged or missing, contact your retailer immediately.
1.4 Monitor introduction 1.4.1 Front view 1 2 3 Close Menu QuickFit Blue Light Filter 4 USB-C I DP ALTERNATE SUPPORT ≥ 3S ON OFF USB-C I DP ALTERNATE SUPPORT 5 0 10 ≥5S USB-C I DP ALTERNATE SUPPORT 1. 1-2 3-way button • Press center button to turn on the OSD menu. • Long press center button for 3s to turn the monitor off. • Press down button over 5s to lock/unlock the keys.
• 2. 3. Status Description White ON Amber Standby mode Dark OFF Quickfit Hotkey • This is a hotkey to activate the QuickFit function designed for alignment. • The QuickFit function contains 3 pages of common grid patterns and photo sizes. See page 1-4 for details. Blue light filter • 4. The color of the power indicator defines as the below table. Adjust the energy level of blue light emitted from LED backlight.
1.4.2 QuickFit Function The QuickFit function contains two patterns: (1) Grid (2) Photo size. 1. Grid pattern: Facilitates designers and users to organize content and layout on one page and achieve a consistent look and feel. Alignment Grid1 2. Photo size: Provides photographers and other users to accurately view and edit their photos in real size on the screen.
2.1 Adjusting the monitor • For optimal viewing, we recommend that you look at the full face of the monitor, then adjust the monitor to the angle that is most comfortable for you. • You can adjust the monitor’s angle by three positions with carrying case. • There are two strips for viewing angle adjustment. For upright position, use the far side strip from the top cover. For tilt-back position, use the other one instead.
2.
3.1 OSD (On-Screen Display) menu 3.1.1 How to reconfigure S Splendid ASUS MB169 Scenery Mode DisplayPort 1920x1080@60Hz Scenery Mode Standard Mode Theater Mode Game Mode Night View Mode sRGB Mode Reading Mode Darkroom Mode 1. Press the MENU button to activate the OSD menu. 2. Press the and buttons to toggle between options in the Menu. As you move from one icon to another, the option name is highlighted. 3. To select the highlighted item on the menu press the center button. 4.
3.1.2 1. OSD Function Introduction Splendid This function contains eight sub-functions that you can select for your preference. S Splendid ASUS MB169 Scenery Mode DisplayPort 1920x1080@60Hz Scenery Mode Standard Mode Theater Mode Game Mode Night View Mode sRGB Mode Reading Mode Darkroom Mode 2. 3-2 • Scenery Mode: This is the best choice for scenery photo displaying with SPLENDID™ Video Intelligence Technology.
S Blue Light Filter ASUS MB169 Scenery Mode DisplayPort 1920x1080@60Hz Level 0 Level 1 Level 2 Level 3 Level 4 • Level 0: No change. • Level 1~4: The higher the level,the more blue light will be reduced. • When Blue Light Filter is activated,the default settings of Standard Mode will be automatically imported. • Between Level 1 to Level 3, the Brightness function is user-configurable. • Level 4 is optimized setting. It is compliance with TUV Low Blue Light Certification.
3. Color Select the image color you like from this function. S Color ASUS MB169 Scenery Mode DisplayPort 1920x1080@60Hz Brightness Contrast Saturation Color Temp. Skin Tone Smart View • Brightness: The adjusting range is from 0 to 100. • Contrast: The adjusting range is from 0 to 100. • Saturation: The adjusting range is from 0 to 100. • Color Temp.: Contains three preset color modes (Cool, Normal, Warm) and User Mode.
S Image ASUS MB169 Scenery Mode DisplayPort 1920x1080@60Hz Sharpness Trace Free Aspect Control VividPixel A SCR • Sharpness: Adjusts the picture sharpness. The adjusting range is from 0 to 100. • Trace Free: Speeds up the response time by Over Drive technology. The adjusting range is from lower 0 to faster 100. • Aspect Control: Adjusts the aspect ratio to “Full”, “4:3”. • VividPixel: ASUS Exclusive Technology that brings lifelike visuals for crystal-clear and detail-oriented enjoyment.
S ASUS MB169 Scenery Mode DisplayPort 1920x1080@60Hz System Setup Back Information Power Indicator Power Key Lock ... All Reset • Splendid Demo Mode: Activate the demo mode for the Splendid function. • GamePlus: The GamePlus Function provides a toolkit and creates a better gaming environment for users when playing different types of games. Particularly, Chrosshair function is specially designed for new gamers or beginners interested in First Person Shooter (FPS) games.
• Key Lock: Disable all key functions. Pressing the second button on the right for more than five seconds to disable key lock function. • More: Return the next page of System Setting. • Back: Return the previous page of System Setting. • Information:Displays the monitor information. • Power Indicator: Turn the power LED indicator on/off. • Power Key Lock: To disable / enable power key • All Reset: Selects “Yes” to revert all settings to the factory default mode.
6. Shortcut Selecting this option allows you to set two shortcut keys. S ASUS MB169 Scenery Mode DisplayPort 1920x1080@60Hz Shortcut Shortcut 1 Shortcut 2 7. • Shortcut 1: User can select from “Blue Light Filter” “Splendid”, “Brightness”, “Contrast”, “Color Temp.”, “QuickFit”, “GamePlus” and set as shortcut key. • Shortcut 2: User can select from “Blue Light Filter” “Splendid”, “Brightness”, “Contrast”, “Color Temp.”, “QuickFit”, “GamePlus” and set as shortcut key.
3.2 Specifications Model MB169C+ Panel Size 15.6” (16:9, 39.62cm) wide screen Resolution 1920 x 1080 Brightness 180 cd/m2 Contrast (Min.) ≧700:1 Display Colors 262 K Digital Input DisplayPort™ Alt Mode for USB Type-C™ Colors Dark Gray Power Consumption ≦7W Operating Temp. 0° ~ 40° Phys. Dimension (WxHxD) 379.1 x 235.8 x 8.5 mm Box Dimension (WxHxD) 435 x 297 x 57 mm Net Weight (Esti.) 0.8 kg Gross Weight (Esti.
3.3 Troubleshooting (FAQ) Problem Power LED is not ON The power LED lights amber and there is no screen image Screen image is too light or dark Screen image bounces or a wave pattern is present in the image Screen image has color defects (white does not look white) Problem 3-10 Possible Solution • Press the button to check if the monitor is in the ON mode. • Check if the USB Type-C cable is properly connected to the monitor and the power outlet.
After connecting with the USB Type-C source device, the power LED lights continuously blinking or showing ASUS logo repeatly • Insufficient power supply from source USB Type-C devices. Please follow below steps: • Press the Blue Light Filter button , and then connect the USB Type-C cable. This operation will enable built-in safe mode. After displaying ASUS logo, please release the Blue Light Filter button. After ASUS Logo disappearing, there is “safe mode” message OSD showing up.
3.3 Supported Timing List PC Supported Primary Timing Resolution Refresh Rate Horizontal Frequency 640x480 60Hz 31.469kHz 640x480 72Hz 37.861kHz 640x480 75Hz 37.5kHz 800x600 56Hz 35.156kHz 800x600 60Hz 37.879kHz 800x600 72Hz 48.077kHz 800x600 75Hz 46.875kHz 1024x768 60Hz 48.363kHz 1024x768 70Hz 56.476kHz 1024x768 75Hz 60.023kHz 1152x864 75Hz 67.5kHz 1280x960 60Hz 60kHz 1280x1024 1280x1024 1440x900 1440x900 1680x1050 1920x1080 60Hz 75Hz 60Hz 75Hz 60Hz 60Hz 63.
SD/HD Timings CEA-861B Formats, SD/HD Supported Primary Timings Resolution Refresh Rate Horizontal Frequency 640x480P 720x480P 720x576P 1280x720P 1280x720P 1920x1080i 1920x1080i 59.94 / 60Hz 59.94 / 60Hz 50Hz 50Hz 59.94 / 60Hz 50Hz 59.94 / 60Hz 31.469 / 31.5kHz 31.469 / 31.5kHz 31.25kHz 37.5kHz 44.955 /45kHz 28.125kHz 33.716 / 33.75kHz CEA-861B Formats, SD/HD Supported Optional Timings Resolution Refresh Rate Horizontal Frequency 1440x480P 1440x576P 1920x1080P 1920x1080P 59.94 / 60Hz 50Hz 50Hz 59.
