Table of contents Notices.......................................................................................................... iii Safety information....................................................................................... iv Care & Cleaning........................................................................................... vi 1.1 Welcome........................................................................................ 1-1 1.2 Package contents..............................
Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Safety information iv • Before setting up the monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose the monitor to rain or moisture. • Never try to open the monitor cabinet. The dangerous high voltages inside the monitor may result in serious physical injury. • If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or your retailer.
• Please use ADP-90YD B of DELTA adapter. WARNING Usage of other than specified head- or earphones can result in hearing loss due to excessive sound pressures. Restriction on Hazardous Substances statement (India) This product complies with the “India E-Waste (Management) Rules, 2016” and prohibits use of Lead, Mercury, Hexavalent Chromium, polybrominated biphenyls(PBBs) and polybrominated diphenyl ethers(PBDEs) in concentration exceeding 0.1% by weight in homogenous materials and 0.
Care & Cleaning • Before you lift or reposition your monitor, it is better to disconnect the cables and power cord. Follow the correct lifting techniques when positioning the monitor. When lifting or carrying the monitor, grasp the edges of the monitor. Do not lift the display by the stand or the cord. • Cleaning. Turn your monitor off and unplug the power cord. Clean the monitor surface with a lint-free, non-abrasive cloth. Stubborn stains may be removed with a cloth dampened with mild cleaner.
Where to find more information Refer to the following sources for additional information and for product and software updates. 1. ASUS websites The ASUS websites worldwide provide updated information on ASUS hardware and software products. Refer to http://www.asus.com 2. Optional documentation Your product package may include optional documentation that may have been added by your dealer. These documents are not part of the standard package.
1.1 Welcome Thank you for purchasing the ASUS® LCD monitor! The latest widescreen LCD monitor from ASUS provides a crisper, broader, and brighter display, plus a host of features that enhance your viewing experience. With these features, you can enjoy the convenience and delightful visual experience that the monitor brings you! 1.
1.3 Assembling the monitor To assemble the monitor: • While assembling the monitor arm/base, we recommend that you keep the monitor inside its EPS (Expanded Polystyrene) packaging. 1. Align the screw hole on the arm with the bundled screw on the base. Then insert the base into the arm. 2. Fix the base to the arm by fastening the bundled screw. 3. Align the triangle marks on the monitor base and the LED projection cover. Then attach the LED projection cover to the monitor base. 4.
1.4 Cable management You can organize the cables with the help of the input/output port cover. • Arranging the cables • Using the input/output port cover : the cover can be attached or detached.
1.5 Connect cables 1.5.1 Rear of the LCD monitor XG32VQ 8 Mini HDMI 1 1-4 2 3 DCIN 4 5 1. HDMI2.0 Port 2. DisplayPort 3. Mini DisplayPort 4. Earphone Jack 5. USB Upstream Port 6. USB Downstream Port 7. DC-IN Port 8.
XG32VQR 8 HDMI-2 HDMI-1 1 2 DCIN 3 4 5 1. HDMI2.0 Port 2. HDMI2.0 Port. 3. DisplayPort 4. Earphone Jack 5. USB Upstream Port 6. USB Downstream Port 7. DC-IN Port 8.
XG35VQ 8 1-6 HDMI-2 HDMI-1 1 2 DCIN 3 4 1. HDMI1.4 Port 2. HDMI2.0 Port. 3. DisplayPort 4. Earphone Jack 5. USB Upstream Port 6. USB Downstream Port 7. DC-IN Port 8.
1.6 Monitor introduction 1.6.1 Using the Controls button Use the control button on the back of the monitor to adjust the monitor settings. 6 6 5 5 4 4 3 3 2 2 1 1. Power Indicator: • 2. The color definition of the power indicator is as the below table. Status Description White ON Amber Standby mode OFF OFF Power Button: • Press this button to turn the monitor on/off.
• Activate Crosshair, Timer, FPS Counter or Display Alignment function • Move the ( ) button up/down to select and press ( to confirm the function needed. Press to go off, and exit. • Crosshair/Timer/FPS Counter is movable by pressing 5-way key. GamePlus main menu ) GamePlus-Crosshair (Practice Mode) GamePlus-Timer GamePlus-FPS Counter GamePlus FPS NEXT 5. Close Button • 6. 1-8 BACK/EXIT Exit the OSD menu. ( 5-way) Button: • Turn on the OSD menu. Enacts the selected OSD menu item.
2.1 Adjusting the monitor • For optimal viewing, we recommend that you look at the full face of the monitor, then adjust the monitor to the angle that is most comfortable for you. • Hold the stand to prevent the monitor from falling when you change its angle. • You can adjust the monitor’s angle from +20˚ to -5˚ and it allows 50˚ swivel adjustment from either left or right. You can also adjust the monitor’s height within +/- 10cm.
2.2 Detaching the arm/stand (for VESA wall mount) • Avoid damaging the monitor surface. While detaching the monitor stand, always keep the monitor inside its EPS packaging. The detachable stand of this monitor is specially designed for VESA wall mount. To detach the arm/stand 2-2 1. Disconnect power and signal cables. Carefully put the monitor facedown on its EPS packaging. 2. Remove the covers on where the monitor and the arm meet. 3.
3.1 OSD (On-Screen Display) menu 3.1.1 How to reconfigure DisplayPort 2560x1440@ 60Hz Racing Mode Aura OFF ROG Strix XG35VQ GameVisual Scenery Mode Blue Light Filter Racing Mode Color Cinema Mode Image RTS/RPG Mode PIP/PBP Setting FPS Mode Input Select sRGB Mode System Setup MOBA Mode MyFavorite User Mode MOVE/ENTER BACK EXIT 1. Press the Central of 5-way button to display the OSD menu. 2. Press the Up and Down keys to switch the options in the menu.
3.1.2 1. OSD Function Introduction GameVisual This function contains eight sub-functions that you can select for your preference.
2. Blue Light Filter Adjust the energy level of blue light emitted from LED backlight. DisplayPort 2560x1440@ 60Hz Racing Mode Aura OFF ROG Strix XG35VQ Level 0 GameVisual Level 1 Blue Light Filter Level 2 Color Level 3 Image Level 4 PIP/PBP Setting Input Select System Setup MyFavorite MOVE/ENTER BACK EXIT • Level 0: No change. • Level 1~4: The higher the level,the more blue light will be reduced.
3. Color Select the image color you like from this function. DisplayPort 2560x1440@ 60Hz Racing Mode Aura OFF ROG Strix XG35VQ GameVisual Blue Light Filter Brightness 90 Contrast 80 Saturation Color Color Temp. Image Gamma PIP/PBP Setting Input Select System Setup MyFavorite MOVE/ENTER EXIT • Brightness: The adjusting range is from 0 to 100. • Contrast: The adjusting range is from 0 to 100. • Saturation: The adjusting range is from 0 to 100. • Color Temp.
• Aspect Control: Adjusts the aspect ratio to “Full” ,“4:3” and “16:9” (Only for XG35VQ). • ASCR: Select ON or OFF to enable or disable dynamic contrast ratio function,ASCR is Disabled when ELMB is on. • ELMB: Check to decrease motion blur and minimize ghosting part when on-screen objects are fast moving. ELMB will be disabled if input source HDMI is selected.
5. PIP/PBP Setting (Only for XG35VQ) The PIP/PBP Setting allows you to open up another sub-window connected from another video source besides the main-window from your original video source.
6. Input Select Select the input source: • HDMI, DisplayPort, and Mini DisplayPort. (for XG32VQ) • HDMI-1 (v2.0), HDMI-2 (v2.0), and DisplayPort. (for XG32VQR) • DisplayPort, HDMI-1 (v2.0), and HDMI-2.
7. System Setup Adjusts the system configuration.
8. • OSD Setup: Adjusts the OSD Timeout, DDC/CI, and Transparency of the OSD screen. • Language: Select OSD language. The selections are: English, French, German, Spanish, Italian, Dutch, Russian, Poland, Czech, Croacia, Hungary, Romania, Portugal, Turkey, Simplified Chinese, Traditional Chinese, Japanese, Korean, Persian, Thai, and Indonesian. • Information:Displays the monitor information. • Key Lock: Disable all key functions.
3.2 Aura AURA is a software program that controls the colorful LEDs on supported devices,such as monitors, motherboards, graphic cards, desktop PCs, etc. Aura allows you to adjust the color of the RGB LEDs on these devices and select different light effects. You can also correct or adjust the color of the LEDs by calibrating them. To activate Aura: 1. Turn ON the Aura Sync function in the OSD menu. 2. Connect the USB 3.0 upstream port of the monitor to the USB port of your computer. 3.
4 Click to undo the changes. 5 Click to apply the changes. If the USB upstream connection between the monitor and computer is disconnected, to resume the Aura function, you need to re-connect the USB 3.0 upstream port of the monitor to the computer and then restart the computer.
3.3 Specifications Model XG32VQ Panel Size 31.5”W (80.1 cm) Max. Resolution 2560x1440 Brightness (Typ.) 300cd/m2 Intrinsic Contrast Ratio (Typ.) Viewing Angle (CR>10) Display Colors 16.7 M Response Time 4ms (G To G ) Sound from HDMI HDMI input DisplayPort input Mini DP1.2 USB3.0 Port Earphone Power ON Consumption Chassis Colors Power saving mode Power off mode Tilt Yes HDMI2.
Model XG32VQR Panel Size 31.5”W (80.1 cm) Max. Resolution 2560x1440 Brightness (Typ.) 450cd/m2 Intrinsic Contrast Ratio (Typ.) Viewing Angle (CR=10) 3000:1 178°(H) /178°(V) Display Colors ≥16.7 M Response Time 4ms (G To G ) Sound from HDMI HDMI input DisplayPort input USB3.0 Port Earphone Power ON Consumption Chassis Colors Yes HDMI2.
Model XG35VQ Panel Size 35”W (88.9 cm) Max. Resolution 3440x1440 Brightness (Typ.) 300cd/m2 Intrinsic Contrast Ratio (Typ.) Viewing Angle (CR>10) Display Colors 16.7 M Response Time 4ms (G To G ), 1ms (MPRT) Sound from HDMI HDMI input DisplayPort input USB3.0 Port Earphone Power ON Consumption Chassis Colors Yes HDMI1.4x1, HDMI2.
3.3 Troubleshooting (FAQ) Problem Power LED is not ON Possible Solution • Press the button to check if the monitor is in the ON mode. • Check if the power cord is properly connected to the monitor and the power outlet. • Check Power Indicator function in main menu OSD. Select “ON” to turn on power LED. The power LED lights amber and • Check if the monitor and the computer are in the there is no screen image ON mode. • Make sure the signal cable is properly connected the monitor and the computer.
3.4 Supported Timing List PC Supported Primary Timing XG32VQ Timing List HDMI2.0 DisplayPort 1.
XG32VQR Timing List HDMI2.0 DisplayPort 1.
XG35VQ 3-18 Timing List HDMI1.4 HDMI2.0 640 x 480 @ 60Hz V V DisplayPort 1.
Video timing XG32VQ Timing List HDMI2.0 DisplayPort 1.2 Mini DP 640x480 @ 59.94Hz V V V 640x480 @ 60Hz V V V 720x480P @ 59.94Hz V V V 720x480P @ 60Hz V V V 720x576P @ 50Hz V V V 1280x720P @ 50Hz V V V 1280x720P @ 59.94Hz V V V 1280x720P @ 60Hz V V V 1440x480P @ 59.94Hz V V V 1440x480P @ 60Hz V V V 1440x576P @ 50Hz V V V 1920x1080P @ 50Hz V V V 1920x1080P @ 59.94Hz V V V 1920x1080P @ 60Hz V V V XG32VQR Timing List HDMI2.0 DisplayPort 1.
XG35VQ Timing List HDMI1.4 HDMI2.0 DisplayPort 1.2 640x480 @ 59.94Hz V V V 640x480 @ 60Hz V V V 720x480P @ 59.94Hz V V V 720x480P @ 60Hz V V V 720x576P @ 50Hz V V V 1280x720P @ 50Hz V V V 1280x720P @ 59.94Hz V V V 1280x720P @ 60Hz V V V 1440x480P @ 59.94Hz V V V 1440x480P @ 60Hz V V V 1440x576P @ 50Hz V V V 1920x1080P @ 50Hz V V V 1920x1080P @ 59.94Hz V V V 1920x1080P @ 60Hz V V V * The modes not listed in the above tables may not be supported.
