PG27AQ series LCD Monitor User Guide
First Edition September 2015 Copyright © 2015 ASUSTeK COMPUTER INC. All Rights Reserved. No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).
Contents Notices.......................................................................................................... iv Safety information........................................................................................ v Care & Cleaning........................................................................................... vi Takeback Services...................................................................................... vii Chapter 1: Product introduction 1.1 Welcome! .......
Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Safety information • Before setting up the monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose the monitor to rain or moisture. • Never try to open the monitor cabinet. The dangerous high voltages inside the monitor may result in serious physical injury. • If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or your retailer.
This symbol of the crossed out wheeled bin indicates that the product (electrical, electronic equipment, and mercury-containing button cell battery) should not be placed in municipal waste. Please check local regulations for disposal of electronic products. AEEE yönetmeliğine uygundur Care & Cleaning • Before you lift or reposition your monitor, it is better to disconnect the cables and power cord. Follow the correct lifting techniques when positioning the monitor.
Where to find more information Refer to the following sources for additional information and for product and software updates. 1. ASUS websites The ASUS websites worldwide provide updated information on ASUS hardware and software products. Refer to http://www.asus.com 2. Optional documentation Your product package may include optional documentation that may have been added by your dealer. These documents are not part of the standard package.
viii
1.1 Welcome! Thank you for purchasing the ASUS® LCD monitor! The latest widescreen LCD monitor from ASUS provides a broader, brighter and crystal-clear display, plus a host of features that enhance your viewing experience. With these features, you can enjoy the convenience and delightful visual experience that the monitor brings to you! 1.
1.3 Monitor introduction 1.3.1 Front view 1 2 3 4 5 1. ( 5-way) button: • Turns on the OSD menu. Enacts the selected OSD menu item. • Increases/Decreases values or moves your selection up/down/left/right. • Turns on the OSD menu when the monitor enters standby mode or displays the “NO SIGNAL“ message. 2. button • Exits the OSD menu item. • Turns on the OSD menu when the monitor enters standby mode or displays the “NO SIGNAL“ message. 3. button: • GamePlus hotkey.
• Turns on the OSD menu when the monitor enters standby mode or displays the “NO SIGNAL“ message. 5. Power button/power indicator • Turns the monitor on/off. • The color definition of the power indicator is as the below table. 1.3.2 Status Description White Amber OFF Red ON Standby mode/No signal OFF G-SYNC Back view 9 4 5 6 7 8 Rear connectors 1. 2. DC-IN port. This port connects the power cord. Earphone jack. This port is only available when an HDMI/DisplayPort cable is connected. 3.
1.3.3 GamePlus Function The GamePlus function provides a toolkit and creates a better gaming environment for users when playing different types of games. In addition, Crosshair function is specially designed for new gamers or beginners interested in First Person Shooter (FPS) games. To active GamePlus: 1. Press the GamePlus hotkey. 2. Move the ( ) button up/down to select among different functions. 3. Press the ( ) button or move the function you choose, and move the through the settings.
1.3.4 GameVisual Function The GameVisual function helps you select among different picture modes in a convenient way. To active GameVisual: Press the GameVisual hotkey repeatedly to select. • Scenery Mode: This is the best choice for scenery photo displaying with GameVisualTM Video intelligence Technology. • Racing Mode: This is the best choice for racing game playing with GameVisualTM Video intelligence Technology.
1-6 Chapter 1: Product introduction
2.1 Adjusting the monitor • For optimal viewing, we recommend that you look at the full face of the monitor, then adjust the monitor to the angle that is most comfortable for you. • Hold the stand to prevent the monitor from falling when you change its angle. • The recommended adjusting angle is +20˚ to -5˚ (for tilt)/+60˚ to -60˚ (for swiveling/ +120 mm (for height adjustment)/90˚ (for portrait view).
2.2 Detaching the arm (for VESA wall mount) The detachable arm of this monitor is specially designed for VESA wall mount. To detach the arm: 1. Have the front of the monitor face down on a table. 2. Loosen the four screws on the back of the monitor and remove the arm/base. 1 2 We recommend that you cover the table surface with soft cloth to prevent damage to the monitor. 2.3 Connecting the cables Connect the cables as the following instructions: • To connect the power cord: a.
b. • Connect one end of the power cord to the power adapter and the other end to a power outlet. To connect the DisplayPort/HDMI cable: a. Plug one end of the DisplayPort/HDMI cable to the monitor’s DisplayPort/HDMI port. b. Connect the other end of the DisplayPort/HDMI cable to your computer's DisplayPort/HDMI port. • To use the earphone: connect the end with plug type to the monitor’s earphone jack when an HDMI or DisplayPort signal is fed. • To use the USB 3.0 ports: Take the supplied USB 3.
2-4 Chapter 2: Setup
3.1 OSD (On-Screen Display) menu 3.1.1 How to reconfigure Normal Mode DisplayPort 3840 x 2160@ 60Hz Racing Mode ASUS ROG PG27A Blue Light Filter Level o Color Level 1 Image Level 2 Input Select Level 3 System Setup Level 4 BACK MOVE/ENTER EXIT 1. Press the ( ) button to activate the OSD menu. 2. Move the ( ) button up/down to navigate through the functions. Highlight the desired function and press the ( ) button to activate it.
• Level 0: No change. • Level 1~4: The higher the level, the less blue light is scattered. When Blue Light Filter is activated,the default settings of Racing Mode will be automatically imported. Between Level 1 to Level 3, the Brightness function is user-configurable. Level 4 is optimized setting. It is compliance with TUV Low Blue Light Certification. The Brightness function is not userconfigurable. Please refer to the following to alleviate eye strains: 2.
3. Image You can adjust OD from this menu. Normal Mode DisplayPort 3840 x 2160@ 60Hz Racing Mode ASUS ROG PG27A Blue Light Filter OD Color Image Input Select System Setup BACK MOVE/ENTER • 4. EXIT OD: Improves the gray level response time of the LCD panel. Input Select In this function, you can select your desired input source. Normal Mode DisplayPort 3840 x 2160@ 60Hz Racing Mode ASUS ROG PG27A Blue Light Filter DisplayPort Color HDMI Image Input Select System Setup BACK MOVE/ENTER 5.
• Transparency: Adjusts the OSD background from opaque to transparent. • OSD Timeout: Adjusts the OSD timeout from 10 to 120 seconds. • Keylock: To disable all function keys. Press the key lock function. • Information: Shows the monitor information. • LIGHT IN MOTION: Select “ON” if you want to turn on the red light on the base. • Sound: over 5 seconds to cancel * Volume: the adjusting range is from 0 to 100. * Mute: toggles the monitor sound between on and off.
3.2 Specifications summary Panel Type Panel size Max. Resolution Pixel pitch Brightness (Typ.) Contrast Ratio (Typ.) Viewing angle(H/V) CR>10 Display colors Response time Color temperature selection Analog input Digital input Earphone jack Audio input Speaker (Built-in) USB 3.0 port Colors Power LED Tilt Swivel Height adjustment VESA wall mount Kensington lock Voltage rating Temperature (Operating) TFT LCD 27”W (16:9, 68.47 cm) wide screen 3840 x 2160 0.155 mm 300 cd/m2 1000:1 178˚/178˚ 1.
Regulation approvals CB, CE, CU, CCC, UL/cUL, FCC, RCM, BSMI, VCCI, RoHS, WEEE, J-MOSS, ErP, PSE, CEL Level 2, Windows 7 WHQL, Windows 8.1 WHQL, Windows 10 WHQL, KCC, E-Standby *Specifications are subject to change without notice. 3.3 Troubleshooting (FAQ) Problem Power LED is not ON The power LED lights amber and there is no screen image Screen image is too light or dark Screen image is not centered or sized properly Possible Solution • Press the button to check if the monitor is in the ON mode.
3.4 Supported operating mode HDMI input Resolution Frequency Refresh Rate 640 x 480 60Hz 800 x 600 60Hz 720 x 480 60Hz 720 x 576 50Hz 1024 x 768 60Hz 1280 x 720 50Hz 1280 x 720 60Hz 1920 x 1080 50Hz 1920 x 1080 60Hz 3840 x 2160 24Hz Note: Do not support interlace. DisplayPort input Resolution Frequency Refresh Rate 640 x 480 60Hz 800 x 600 60Hz 1024 x 768 60Hz 1920 x 1080 60Hz 3840 x 2160 24Hz 3840 x 2160 30Hz 3840 x 2160 60Hz Note: Do not support interlace.
