VG32V Series LCD Monitor User Guide
Table of contents Notices.......................................................................................................... iii Safety information....................................................................................... iv Care & Cleaning........................................................................................... vi 1.1 Welcome!....................................................................................... 1-1 1.2 Package contents..............................
Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Safety information iv • Before setting up the monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose the monitor to rain or moisture. • Never try to open the monitor cabinet. The dangerous high voltages inside the monitor may result in serious physical injury. • If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or your retailer.
WARNING Usage of other than specified head- or earphones can result in hearing loss due to excessive sound pressures.
Care & Cleaning • Before you lift or reposition your monitor, it is better to disconnect the cables and power cord. Follow the correct lifting techniques when positioning the monitor. When lifting or carrying the monitor, grasp the edges of the monitor. Do not lift the display by the stand or the cord. • Cleaning. Turn your monitor off and unplug the power cord. Clean the monitor surface with a lint-free, non-abrasive cloth. Stubborn stains may be removed with a cloth dampened with mild cleaner.
Where to find more information Refer to the following sources for additional information and for product and software updates. 1. ASUS websites The ASUS websites worldwide provide updated information on ASUS hardware and software products. Refer to http://www.asus.com 2. Optional documentation Your product package may include optional documentation that may have been added by your dealer. These documents are not part of the standard package.
1.1 Welcome! Thank you for purchasing the ASUS® LCD monitor! The latest widescreen LCD monitor from ASUS provides a crisper, broader, and brighter display, plus a host of features that enhance your viewing experience. With these features, you can enjoy the convenience and delightful visual experience that the monitor brings you! 1.
1.3 Assembling the monitor To assemble the monitor: • While assembling the monitor arm/base, we recommend that you keep the monitor inside its EPS (Expanded Polystyrene) packaging. 1. Align the screw hole on the arm with the bundled screw on the base. Then insert the base into the arm. 2. Fix the base to the arm by fastening the bundled screw.
1.4 Connect cables 1.4.1 Rear of the LCD monitor 6 HDMI-2 HDMI-1 4 3 5 1. DC-IN Port 2. DisplayPort 3. HDMI-1 Port 4. HDMI-2 Port 5. Earphone - out Port 6.
1.5 Monitor introduction 1.5.1 Using the Controls button Use the control button on the bottom of the monitor to adjust the image settings. 6 6 5 5 4 4 3 3 2 2 1 1. Power Indicator: • 2. The color definition of the power indicator is as the below table. Status Description White ON Amber Standby mode OFF OFF Power Button: • Press this button to turn the monitor on/off.
• Activate Crosshair, Timer or FPS Counter or Display Alignment function. • Move the ( ) button up/down to select and press ( confirm the function needed. Press to go off, and exit. • Crosshair/Timer/FPS Counter is movable by pressing • To activate Sniper, you need to disable HDR on your device. ) to 5-way key. GamePlus main menu GamePlus-Crosshair GamePlus-Timer GamePlus-Sniper 5. Close Button: • Exit the OSD menu. • • (5-way) Button: Turns on the OSD menu.
2.1 Adjusting the monitor • For optimal viewing, we recommend that you look at the full face of the monitor, then adjust the monitor to the angle that is most comfortable for you. • Hold the stand to prevent the monitor from falling when you change its angle. • You can adjust the monitor’s angle from +20˚ to -5˚ and it allows 62˚ swivel adjustment from either left or right. You can also adjust the monitor’s height within +/- 14cm.
2.2 Detaching the arm/stand (for VESA wall mount) The detachable stand of this monitor is specially designed for VESA wall mount. To detach the arm/stand 2-2 1. Disconnect power and signal cables. Carefully put the monitor facedown on its EPS packaging. 2. Remove the screws covers. 3. Remove the four (4) screws securing the arm to the rear of the monitor. 4. Detach the stand (arm and base) from the monitor. • The VESA wall mount kit ( 100 x 100 mm) is purchased separately.
2.
3.1 OSD (On-Screen Display) menu 3.1.1 How to reconfigure GameVisual ASUS VG32V HDR OFF Racing Mode DisplayPort 1920x1080@120Hz Scenery Mode Racing Mode Cinema Mode RTS/RPG Mode FPS Mode sRGB Mode MOBA Mode 1. Press Central of 5-way to activate the OSD menu. 2. Press the and buttons to toggle between options in the Menu. As you move from one icon to another, the option name is highlighted. 3. To select the highlighted item on the menu press the Center key. 4.
3.1.2 1. OSD Function Introduction GameVisual This function contains seven sub-functions that you can select for your preference. Each mode has the Reset selection, allowing you to maintain your setting or return to the preset mode. GameVisual ASUS VG32V HDR OFF Racing Mode DisplayPort 1920x1080@120Hz Scenery Mode Racing Mode Cinema Mode RTS/RPG Mode FPS Mode sRGB Mode MOBA Mode 3-2 • Scenery Mode: This is the best choice for scenery photo displaying with GameVisual™ Video Intelligence Technology.
2. Blue Light Filter Adjust the energy level of blue light emitted from LED backlight. Blue Light Filter ASUS VG32V HDR OFF Racing Mode DisplayPort 1920x1080@120Hz Level 0 Level 1 Level 2 Level 3 Level 4 • Level 0: No change. • Level 1~4: The higher the level,the more blue light will be reduced. • When Blue Light Filter is activated,the default settings of Racing Mode will be automatically imported. • Between Level 1 to Level 3, the Brightness function is user-configurable.
3. Color Select the image color you like from this function. Color ASUS VG32V HDR OFF Racing Mode DisplayPort 1920x1080@120Hz Brightness Contrast Saturation Color Temp. Skin Tone • Brightness: The adjusting range is from 0 to 100. • Contrast: The adjusting range is from 0 to 100. • Saturation: The adjusting range is from 0 to 100. • Color Temp.: Contains three preset color modes (Cool, Normal, Warm) and User Mode.
4. Image You can adjust the image HDR, Sharpness, VividPixel, AdaptiveSync/FreeSync, ELMB SYNC, Shadow Boost, Aspect Control, ASCR, Trace Free from this main function. Image ASUS VG32V HDR OFF Racing Mode DisplayPort 1920x1080@120Hz HDR Sharpness VividPixel Adaptive-Sync/FreeSync ELMB SYNC Shadow Boost Aspect Control More Image ASUS VG32V HDR OFF Racing Mode DisplayPort 1920x1080@120Hz Back ASCR Trace Free • HDR:High Dynamic Range. Contains two HDR modes (ASUS Cinema HDR and ASUS Gaming HDR).
• Aspect Control: Adjusts the aspect ratio to “Full”, “4:3” and “OverScan”. • ASCR: Select ON or OFF to enable or disable dynamic contrast ratio function,ASCR is Disabled when ELMB is on. • Trace Free: Speeds up the response time by Over Drive technology. The adjusting range is from lower 0 to faster 100. • 5. 4:3 is only available when input source is in 4:3 format。OverScan is only available for the HDMI input source.
System Setup ASUS VG32V HDR OFF Racing Mode DisplayPort 1920x1080@120Hz Back Power Indicator Power Key Lock All Reset • GameVisual Demo Mode: Activate the demo mode for the GameVisual function. • Volume: Adjusts the output volume level. • ECO Mode: Activate the ecology mode for power saving. • OSD Setup: Adjusts the OSD Timeout, DDC/CI, and Transparency of the OSD screen. • Language: Select OSD language.
7. MyFavorite Load/Save all settings on the monitor.
3.2 Specifications Model VG32VQ Panel Size 31.5”W (80.1cm) Max. Resolution 2560x1440@144Hz Brightness (Typ.) 400cd/m2 Intrinsic Contrast Ratio (Typ.) 3000:1 Viewing Angle (CR=10) 178°(V) /178°(H) Display Colors 16.7 M(True 8bit) Color Saturation 72% NTSC Response Time 4ms (Gray to Gray), 1ms MPRT Satellite Speaker 2W x 2 stereo Earphone Output Yes Sound from HDMI Yes HDMI input Yes DisplayPort input Power ON Consumption(Max.
3.3 Troubleshooting (FAQ) Problem Power LED is not ON Possible Solution • Press the button to check if the monitor is in the ON mode. • Check if the power cord is properly connected to the monitor and the power outlet. • Check Power Indicator function in main menu OSD. Select “ON” to turn on power LED. The power LED lights amber and • Check if the monitor and the computer are in the there is no screen image ON mode. • Make sure the signal cable is properly connected the monitor and the computer.
3.4 Supported Timing List PC Timings List of HDMI2.0 / DP1.2 input Resolution HDMI1(2.0) HDMI2(2.
