Disassembly procedure 2 Chapter Disassembly Procedure Please follow the information provided in this section to perform the complete disassembly procedure of the notebook. Be sure to use proper tools described before. A SUS V1S Series Notebook consists of various modules. This chapter describes the procedures for the complete notebook disassembly. In addition, in between procedures, the detailed disassembly procedure of individual modules will be provided for your service needs.
Disassembly procedure B A T T E R Y Battery Module The illustration below shows how to remove the battery module. Remove battery module 1. Turn the notebook over. Unlock and hold the latch, and remove the battery. 2 3 1 C P U M O D U L E R E M O V A L C P U R E M O V A L CPU Module The illustrations below show how to remove the CPU module from the notebook. Removing CPU 1. Remove 5 screws (M2*5) and take the CPU door away.
Disassembly procedure Remove VGA board module 2. Remove 4 screws(M2*5)(M2*3),then remove the VGA board module M2*5 M2*3 3. Remove the DIMM cover from the bottom case. 4. Remove 4 screws (M2*5) aside the CPU. And disconnect the CPU fan cable..
Disassembly procedure 5. Remove the CPU thermal module from the bottom case. 6. Turn the non-removable screw here 180 degrees counter-clockwise to loosen the CPU. 7. Squeeze the vacuum handling pump and use it to lift the CPU away.
Disassembly procedure M E M O R Y M O D U L E M E M O R Y R E M O V A L Memory Module The illustration shows how to remove the memory module form the notebook. Removing Memory module 1. Pull two latches and pop the module up to a 45° angles, and then pulling out the module in that angle. 45o H D D M O D U L E H D D M O D U L E R E M O V A L HDD Module The illustrations below show how to remove the HDD module from the notebook. Removing HDD Module 1.
Disassembly procedure 2. Remove the HDD door from the bottom case and then put the HDD module. 3.
Disassembly procedure O P T I C A L D R I V E Optical Drive Module 1. Unlock and hold the latch, and remove the ODD module. R E M O V A L K E Y B O A R D Keyboard Module The illustration of below shows how to remove the keyboard Removing Keyboard 1. Remove 1 screw (M2*5) here, and then turn over the notebook. 2. Push the 4 latches in (F1, F6, F10, Ins) with a pair of tweezers or a single-slotted screwdriver and lift the keyboard plate up.
Disassembly procedure 3. Lay the keyboard down over the Top case. *Do not remove the keyboard yet. The keyboard cable is still attached. 4. Disconnect the FPC connector by a pair of tweezers. Removing Keyboard Cable 1. Use a flexible connector tool to unlock the cable connector on both ends (no. 1). 2. Carefully pull out the keyboard cable (no. 2) with a pair of tweezers. 3. Lock the connector (no. 3) again to avoid possible breakage. 2. Cable out 1. Unlock 3. 1. Unlock 3. 4.
Disassembly procedure T O P C A S E M O D U L E T O P C A S E R E M O V A L Top Case Module The illustrations below show how to disassemble and remove the top case module of the notebook. The module contains the top case itself. Removing Top Case Module 1. Use a pair of tweezers to remove both hinge Cover. 2. Use a pair of tweezers to disconnect both speaker cables.
Disassembly procedure 3. Disconnect the touchpad FPC and antenna. Antenna Touchpad FPC 4. Disconnect the LCD cable and inverter cable and switch board FFC.
Disassembly procedure 5. Remove 2 screws (M2*5) here. 6. Turn over the notebook and then remove 17 screws here. M2.5*2 M2*5 M2*4 7. Separate the Top case from the bottom case.
Disassembly procedure 8. Separate the antenna from the top case. 9. Remove 8 screws (M2.5*6) here. 10. Separate the top case from the LCD module.
Disassembly procedure 11. Remove 4 screws (M2*3) here and then take away the speaker. 12. Remove 4 screws (M2*2.5) here then take away the switch board. 13. Disconnect the Bluetooth cable and remove Bluetooth Mylar. Then remove Bluetooth module from the top case.
Disassembly procedure 14. Remove 3 screws (M2*3) here then take away the touchpad bracket. 15. Remove 6 screws (M2*3) here and then take away the touchpad board. 16. Use a pair of tweezers to disconnect touchpad cable and FFC cable..
Disassembly procedure 17. Remove 2 screws (M2*3) here and then take away the touchpad module from the top case. W L A N M O D U L E WLAN Module The illustrations below show how to remove the WLAN module from the notebook. Remove WLAN module W L A N 1. Remove 2 Antenna cables from Wireless LAN Module M O D U L E R E M O V A L 2. Pull two latches and pop the module up to a 45° angles, and then pulling out the module in that angle.
Disassembly procedure 3 G C A R D & 3 G Card and Robson Card The disassembly method of 3 G card and Robson card goes the same with that of the WLAN module. R O B S O N C A R D 3 G card M O T H E R B O A R D M O T H E R B O A R D R E M O V A L Robson card Motherboard The illustrations below show how to disassemble and remove the Motherboard. Removing Motherboard 1. Disconnect the modem cable to motherboard. 2. Remove 2 screws here and then take away the modem module.
Disassembly procedure 3. Remove 6 screws here. M2*5 M2*8 4. Separate the Motherboard from the bottom case. 5. Disconnect the DC IN board cable from the motherboard and then take away the board.
Disassembly procedure 6. Remove the 1 screw here the take away the TPM Board. 7. Disconnect the ODD FPC from the mother board.
Disassembly procedure L C D M O D U L E LCD Module The illustrations below show how to remove and disassemble the LCD module. The module contains LCD panel, Inverter board, LCD bezel, LCD back cover. L C D M O D U L E D I S A S S E M B L Y Disassembling LCD Module 1. Remove 6 rubber pads and 6 screws (M2*5)from LCD module. 2. Prying the inside edges of the LCD bezel, and then separates it from LCD back cover. 3. Remove 1 screw (M2*3) here.
Disassembly procedure 4. Disconnect the LCD cable. and inverter cable and then remove inverter board. 5. Remove 4screws (M2*5) and take away the LCD panel.
Disassembly procedure 6. Remove the LCD plane from the LCD back cover. 7. Remove 4 screws (M2*3) on the right LCD bracket to disassemble the LCD bracket. 8. Remove 4 screws (M2*3) on the left LCD bracket to disassemble the other LCD bracket.
Disassembly procedure 9. Disconnect the coaxial cable from LCD plane then take it away. 10. Remove 4 screws (M2*3) here then take away the LCD bracket. 11 Remove 2 screws (M2*5) here and take them away.
Disassembly procedure 12. Remove 6 pieces of tapes then take away the camera module. 13. Remove 1 screw and 4 pieces of tapes then take away the wireless black wire. 14. Remove 1 screw and 3 pieces of tapes then take away the white wire.
