User Guide E11806
First Edition/ July 2016 Model: ASUS_Z012DC (ZE552KL) Before you start, ensure that you have read all the safety information and operating instructions in this User Guide to prevent injury or damage to your device. NOTE: For the latest updates and more detailed information, please visit www.asus.com.
Side features Audio jack Volume Key Micro SIM, Nano SIM / MicroSD combo card slot Power Key Microphone Speaker USB Type-C port NOTE: The USB Type-C port supports USB2.0 transfer rate.
Rear features Rear camera Laser focus RGB sensor Camera flash Finger print sensor Rear cover
Charging your ASUS Phone To charge your ASUS Phone: 1. Connect the USB connector into the power adapter’s USB port. 2. Connect the other end of the USB Type C cable to your ASUS Phone. 3. Plug the power adapter into a wall socket. 3 2 1 IMPORTANT! • When using your ASUS Phone while it is plugged to a power outlet, the grounded power outlet must be near to the unit and easily accessible.
Installing a Micro SIM / Nano SIM / MicroSD card To install a Micro SIM / Nano SIM / MicroSD card: 1. Push a pin into the hole on the Micro SIM / Nano SIM / MicroSD card tray to eject it. 2. Insert the Micro SIM / Nano SIM or MicroSD card(s) into the card slot(s). Micro-SIM1 Micro SD Micro-SIM1 Nano-SIM2 IMPORTANT: You can only use the Nano SIM card or the MicroSD card at a time.
3. Push the tray to close it. NOTES: • • The Micro SIM / Nano SIM card slots support LTE, WCDMA and GSM/EDGE network bands. The MicroSD card slot supports MicroSD and MicroSDHC card formats. IMPORTANT: Both Micro SIM and Nano SIM card slots support 3G WCDMA/ 4G LTE network band. But only one SIM card can connect to 4G LTE service at a time. CAUTION! • Do not use sharp tools or solvent on your device to avoid scratches on it. • Use only a standard Micro SIM card on your ASUS Phone.
Federal Communications Commission Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment.
The country code selection is for non-US model only and is not available to all US model. Per FCC regulation, all WiFi product marketed in US must fixed to US operation channels only.
Canada, Industry Canada (IC) Notices This device complies with Industry Canada’s licence-exempt RSS standard(s. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence.
used in such a manner such that the potential for human contact during normal operation is minimized. This device has been evaluated for and shown compliant with the IC Specific Absorption Rate (“SAR”) limits when installed in specific host products operated in portable exposure conditions. Canada’s REL (Radio Equipment List) can be found at the following web address: http://www.ic.gc.ca/ app/sitt/reltel/srch/nwRdSrch.
Caution (i) the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; Avertissement Le guide d’utilisation des dispositifs pour réseaux locaux doit inclure des instructions précises sur les restrictions susmentionnées, notamment: (i) les dispositifs fonctionnant dans la bande 5 150-5 250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudici
CAUTION: High-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices. AVERTISSEMENT: Les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5250-5350 MHz et 5650-5850 MHz et que ces radars pourraient causer du brouillage et/ou des dommages aux dispositifs LAN-EL.
The highest FCC SAR values for the device are as follows: • 1.17 W/Kg (Head) • 0.59 W/Kg (Body-worn) The FCC has granted an Equipment Authorization for this device with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this device is on file with the FCC and can be found under the Display Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID: MSQZ012DC.
Radio and Telecommunications Equipment and mutual recognition of conformity. The highest CE SAR values for the device are as follows: • 0.493 W/Kg (Head) • 1.460 W/Kg (Body) Laser safety information CLASS 1 LASER PRODUCT This equipment may be operated in: IT PT RU HU FR DE TR RO CZ WB PO SI SK UA ES KZ NOTE: This device is restricted to indoor use only when operating in the 5150 to 5350 MHz frequency range.
Prevention of Hearing Loss To prevent possible hearing damage, do not listen at high volume levels for long periods. For France, headphones/earphones for this device are compliant with the sound pressure level requirement laid down in the applicable EN 503321:2013 and/or EN50332-2:2013 standard required by French Article L.5232-1. Safety information ASUS Phone care • Use your ASUS Phone in an environment with ambient temperatures between 0 °C (32 °F) and 35 °C (95 °F).
• • • Do not remove the non-detachable Li-polymer battery as this will void the warranty. Avoid charging in extremely high or low temperature. The battery performs optimally in an ambient temperature of +5 °C to +35 °C. Do not remove and replace the battery with a non-approved battery. • Use only ASUS battery. Using a different battery may cause physical harm/injury and may damage your device. • Do not remove and soak the battery in water or any other liquid.
Caution Your ASUS Phone is a high quality piece of equipment. Before operating, read all instructions and cautionary markings on the (1) AC Adapter. • Do not use the ASUS Phone in an extreme environment where high temperature or high humidity exists. The ASUS Phone performs optimally in an ambient temperature between 0 °C (32 °F) and 35 °C (95 °F). • Do not disassemble the ASUS Phone or its accessories. If service or repair is required, return the unit to an authorized service center.
Regional notice for Singapore This ASUS Phone complies with IDA Standards. Proper disposal Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. DO NOT throw the battery in municipal waste. The symbol of the crossed out wheeled bin indicates that the battery should not be placed in municipal waste. DO NOT throw this product in municipal waste. This product has been designed to enable proper reuse of parts and recycling.
EU Declaration of Conformity We, the undersigned, Manufacturer: ASUSTeK COMPUTER INC. Address: 4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN Authorized representative in Europe: ASUS COMPUTER GmbH Address, City: HARKORT STR.
Declaraţie de conformitate UE Subsemnatul, Producător : ASUSTeK COMPUTER INC. Adresă: 4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN Reprezentant autorizat în Europa: ASUS COMPUTER GmbH Adresă, Oraş: HARKORT STR.
EU Konformitätserklärung Hiermit erklären wir, Hersteller: ASUSTeK COMPUTER INC. Anschrift: 4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN Bevollmächtigter: ASUS COMPUTER GmbH Anschrift des Bevollmächtigten: HARKORT STR.
DECLARATION UE DE CONFORMITE Nous, soussignés Fabricant: ASUSTeK COMPUTER INC. Adresse: 4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN Représentant autorisé en Europe: ASUS COMPUTER GmbH Adresse, ville: HARKORT STR.
ASUS Address: 4F, 150 Li-Te Road, Peitou, Taipei, Taiwan Tel: 886228943447 Fax: 886228907698 Declaration We declare that the IMEI codes for this product, ASUS Phone, are unique to each unit and only assigned to this model. The IMEI of each unit is factory set and cannot be altered by the user and that it complies with the relevant IMEI integrity related requirements expressed in the GSM standards. Should you have any questions or comments regarding this matter, please contact us.
