Input Zone / Group Options
These options apply to zones or groups already configured as inputs
(see “Type of Zone,” Step 17). These options are summarized in the
Programming Quick Reference Chart, at the end of this section.
27
Tone Selection
If a zone is configured to be an input and is activated, then a tone may
be selected to be directed to whatever zone(s) are selected in “Tone
Routing,” below. The tone selections are listed in step 3.
For example, you wish to have a doorbell pushbutton input cause a
chime to be heard in certain zones. You have already configured the
zone of the doorbell as an input zone. You need to select the tone
(chime) you wish to be heard in the output zones, when the doorbell is
pressed. This is called “Activate Tone via an Input Closure,” on the
Quick Reference Chart.
The default setting for this option is NONE (not activated).
1.
2.
3.
0
1
2
3
4
5
6
7
4.
Dial 9 2 to select this mode option.
Hear a DOUBLE beep.
Enter the number of the input zone (i.e., the zone containing the
doorbell pushbutton). Use ALlAS numbers, if optioned. Otherwise,
use Physical zone/group numbers.
Hear a DOUBLE beep.
Enter the tone option, 0 through 7.
None
Chime
Siren
Warble Siren
Night Bell
Fast Ring
Steady Tone
Door Bell
Hear TRIPLE beeps.
To verify the tone option for a given input zone, dial 9 3 and repeat
steps 2 and 3 above.
Continued on next page...
