Heavy Duty Wheel Dolly Operating Instructions & Parts Manual Model Number Capacity Atd-7227 3/4 Ton (1500 Lbs) Atd Tools Inc.
Save these instructions. For your safety, read and understand the information contained within. The owner and operator shall have an understanding of this product and safe operating procedures before attempting to use this product. Instructions and Safety information shall be conveyed in the operators native language before use of this product is authorized. Make certain that the operator thoroughly understands the inherent dangers associated with the use and misuse of the product.
BEFORE USE ! 1. Inspect before each use. Do not use if bent, broken, leaking or cracked components are noted. Ensure that casters, rollers and lifting arms move freely. Check and tighten any loose assemblies. 2. Verify that the product and the application are compatible, if in doubt call Atd Tools Technical Service (636)272-9050. 3. Read, understand and follow vehicle manufacturer’s recommended tire change procedures. 4. With ram lowered, locate and remove oil filler plug.
HOW TO USE MAINTENANCE 1. Set emergency brake, chock tires of diagonally opposed wheel(s) in both directions AND take every precaution necessary to ensure set up is stable and prevent inadvertent vehicle movement. 2. When tire & wheel assembly are ready to remove, position wheel dolly to accept tire & wheel assembly and secure load with restraint. 3. Use jack handle to turn release valve clockwise until tight. DO NOT OVERTIGHTEN.
TROUBLESHOOTING Symptom Possible Causes Corrective Action • Release valve not tightly closed • Ensure release valve tightly closed Hydraulic unit will not lift load • Overload condition • Remedy overload condition Hydraulic unit bleeds off after • Release valve not tightly closed • Ensure release valve tightly closed • Overload condition • Remedy overload condition lift • Hydraulic unit malfunction • Contact Atd Tools Tech.
REPLACEMENT PARTS Available Parts: Please refer to the Parts drawing when ordering parts. Not all components of the dolly are replacement items, but are illustrated as a convenient reference of location and position in the assembly sequence. When ordering parts, give Model number, serial number and description below. Call or write for current pricing: Atd Tools Inc.
