Appendix
125
Optional Rack Mounting
For convenience and flexibility, three optional rack mounting kits are
available:
A long bracket standard rack mounting kit for 68
–105 cm racks;
A short bracket Easy-Installation rack mount kit for 57
–70 cm racks;
A long bracket Easy-Installation rack mount kit for 68
–105 cm racks.
To install the long bracket standard rack mount kit, simply replace the short L
brackets on the standard rack mount kit with the long ones, and mount the
switch according to the instructions that begin on page 13.
With an Easy-Installation, kit, one person can mount the switch. To install the
Easy-Installation kit, do the following:
1. Remove the standard L brackets and the side mounting brackets from both
sides of the switch.
Phillips head hex
M3 x 4
