Specification Sheet

The Gen 2 Electrically Isolated USB EZO™ Carrier Board works with all EZO™ class devices.
The Gen 2 Electrically Isolated USB EZO™ Carrier Board does not come with EZO™ class devices.
Proper setup for use with the
EZO
™
Universal Flow Meter Totalizer
Connect Flow breakout board
to the carrier board.
R
R BW
W B
Atlas Scientific
Atlas-Scientific.com
Copyright © Atlas Scientific LLC All Rights Reserved
Gen 2 Electrically Isolated USB
EZO™ Carrier Board
