INSTRUCTION MANUAL

Programmable Electronic Thermostat

MODEL TH141A-HC-28

We thank you for trusting Aube technologies and hope that you will be

entirely satisfied.

For any questions concerning the TH141A-HC-28 progammable

electronic thermostat, please call our Technical Support Department at:

1-800-831-AUBE (2823)

Montreal Area : (450) 358-4600

www.aubetech.com service@aubetech.com

TABLE OF CONTENTS

1. INSTALLATION.............................................1

1.1 Remove the Old Thermostat. . . . . . . . .........................1

1.2 Install the New Thermostat . . . . . . . . . .........................1

1.3 Install and Connect the Thermostat . . .........................2

1.4 Identify the Wires .........................................3

1.5 Connect the Labelled Wires to the Thermostat . . . . ...............4

1.6 Wiring Diagrams..........................................4

1.6.1 2- Wire Heating System . . . .........................4

1.6.2 3- Wire Heating System with Fan Control ...............5

1.6.3 3- Wire Air Conditioning System with Fan Control . ........5

1.6.4 4- Wire Heating and Air Conditioning System . . . . ........5

1.6.5 5- Wire Heating and Air Conditioning System . . . . ........6

1.7 Thermostat Configuration...................................6

a) 24 hrs. or 12 hrs. Display. . . . . . .........................6

b) Temperature in °C or °F ................................7

c) Regulation Modes . . . .......................................7

1 - Proportional Adaptive. . ................................7

Regulation cycles . . . . ................................9

2 - Conventional with anticipation. . . . . .....................10

Programmable Span . . . . . ............................10

d) Heating Fan Control. . . . . . . . . . ..............................11

1.8 Battery Installation . . . . . . . . . . ..............................12

2. ENTRY OF BASIC DATA ......................................13

2.1 Programming the Time and Day..............................13

2.2 Programming the Comfort, Economic and Vacation Settings . . ......13

2.3 Programming the Air Conditioning Settings. . . . . . . . .............14

3. OPERATING MODES ........................................15

3.1 Manual. . ...............................................15

3.2 Automatic...............................................15

3.2.1 Schedule Programming . . . . . . . . . ....................15

a) To Program your Schedule. . . . . . . ....................

Summary of content (9 pages)

PAGE 1
INSTRUCTION MANUAL We thank you for trusting Aube technologies and hope that you will be entirely satisfied. For any questions concerning the TH141A-HC-28 progammable electronic thermostat, please call our Technical Support Department at: Programmable Electronic Thermostat MODEL TH141A-HC-28 TABLE OF CONTENTS 1. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1.1 Remove the Old Thermostat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PAGE 2
1. INSTALLATION b) To Erase a Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 c) Example 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 d) Example 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 3.2.2 Temporary or Permanent Temperature Bypass. . . . . . . . . . . . . . . . . . 19 4. SELECT 5. FAN THE HEATING, AIR CONDITIONING, OR MIXED MODE . CONTROL 1.1 REMOVE . . . . . . . . . .
PAGE 3
1.5 CONNECT 1.6.2 3-WIRE THE LABELLED WIRES TO THE THERMOSTAT 1. Connect the system wires to the thermostat terminals according to the wiring diagram shown in section 1.6. 2. Make sure that the wires are pushed well back into the wall. 3. If you own a CT240 telephone controller, refer to section 6.1 for connection. 1. 2. 3. 4. 1.6 WIRING 1.6.3 3-WIRE DIAGRAMS The TH141 thermostat is compatible with most heating and air conditioning systems.
PAGE 4
Ideal for: • Radiant or convection electrical heating system • Circulator control in a hot water system • Electrical hot air furnace • Hot air, gas or fuel conventional furnace • Air-conditioning system Not recommended for: • Gas or fuel furnace or boiler with wall chimney, if they include a combustion gas purging cycle exceeding 30 seconds. To verify this point, check the duration of the delay between the heating command sent by the thermostat and the moment when the burner actually goes on.
PAGE 5
1.8 BATTERY 2. ENTRY OF BASIC DATA INSTALLATION When you first install the batteries in the TH141, the unit runs a sequence of tests and a complete reset to zero, which last approximately 5 seconds. The screen should display the time and the day, as well as the current temperature as follows: It is normal for the displayed temperature to be higher than the room temperature if your are holding the TH141 in your hands, It will return to normal about one hour after installation on the wall.
PAGE 6
Program 1 2 3 4 Note: Mode 3. Press the Program button to select program 1, 2, 3 or 4. 4. Press the Hour and Minute buttons to program the time. 5. When you have completed your programming, press the Manual/Auto button to exit this function. Time Wake-up time Leaving time Return time Bed time For temperature increases (Prog. 1 and 3), allow at least 15 minutes per °C. If you have lowered the temperature by 3 °C during the night and you wake up at 7 AM, change the setting at 6:15 AM.
PAGE 7
You can also switch to the Vacation setting for a prolonged absence by pressing the button. In that case, the derogation is permanent. To return to the normal operating mode, press the Manual/Auto button. If you wish to immediately return to the programmed settings, press the Manual/Auto button twice. 4. SELECT THE HEATING, AIR CONDITIONING, OR MIXED MODE Use the Heat/Cool button to select one of the following modes: Heating: Controls the heating unit according to the displayed setting.
PAGE 8
7. BATTERY REPLACEMENT 8. TECHNICAL SPECIFICATIONS The TH141 will display an icon indicating that the batteries must be replaced. This icon will flash for 60 days. After this delay, the thermostat will shut down your heating unit. During battery replacement, the data is kept for 15 seconds. The time and the programs will not be lost. After this delay, the TH141 runs a sequence of tests and a complete reset to zero as for the initial installation of the batteries.
PAGE 9
27/03/00 720-141A2802
