USER’S MANUAL AMD 808BT BLUETOOTH CD/MP3 PLAYER WITH RADIO AM/FM RDS USB-SD/MMC BUILT IN 10R-02 1005
PANEL RELEASE BUTTON AMS/ DISPLAY/ FUNCTION MP3 ID3 TAG SELECT TALK MENU INFORMATION BUTTON BUTTON BUTTON BUTTON CD SLOT EJECT BUTTON MIC MONO ST AF MOD TA LOCAL LOUD POP CLASSIC DSP PTY CD TP 7 8 9 PTY TA AF ENTER 1 2 SCN 3 RPT 4 SHF 5 DN 6 UP POWER ENCODER BAND/ PTY CD CD TA AF CD CD DIRECTORY BUTTON VOLUME LOUDNESS/ PAUSE SCAN REPEAT SHUFFLE UP/ DOWN BUTTON BUTTON BUTTON MP3 KNOB BUTTON BUTTON BUTTON BUTTON ENTER BUTTON MUTE BUTTON MICROPHONE MODE BUTTON DSP BUTTON MIC M
HANDLING COMPACT DISCS MOISTURE CONDENSATION On a rainy day or in a very damp area, moisture may condense on the lenses inside the unit. Should this occur, the unit will not operate properly. In such a case, remove the disc and wait for about an hour until the moisture has evaporated. NOTES ON CDs NOTES ON DISCS 1. A dirty or defective disc may cause sound dropouts while playing. To enjoy optimum sound, handle the disc as follows. Handle the disc by its edge.
INSTALLATION Before finally installing the unit, connect the wiring temporarily and make sure it is all connected up properly and the unit and system work properly. Use only the parts included with the unit to ensure proper installation. The use of unauthorized parts can cause malfunctions. Consult with your nearest dealer if installation requires the drilling of holes or other modifications of the vehicle.
DIN REAR-MOUNT (METHOD B) Installation using the screw holes on the sides of the unit. Fastening the unit to the factory radio mounting bracket. 2 4 5 3 2 1. Select a position where the screw holes of the bracket and the screw holes of the main unit become aligned (are fitted) and tighten the screws at 2 places on each side. 2. Screw 3. Factory radio mounting bracket. 4. Dashboard or Console 5.
ELECTRICAL CONNECTION a. Make sure your car battery is a 12 volt (6 filler caps) negative ground system (if not, a converter will be necessary). b. Before starting wiring connections, disconnect the power supply by removing the fuse from the fuse box. c. Connect the power wire to one of the extra terminals of the fuse box. d. Connect the black ground wire to a metal part of the car. It is important to make good contact. e. Make other wiring connections as shown. f.
RESET BUTTON The RESET button is located on the main unit (as shown on the diagram). To press it vertically with a ballpoint pen or metal object will activate it. The reset button is to be activated for the following reasons: Initial installation of the unit when all wiring is completed. All the function buttons do not operate. Error symbol on the display.
AUTO MEMORY STORE/PRESET SCAN BUTTON (AMS) 1.PRESET SCAN: Press AMS button briefly enter Preset Scan mode, it will scan all the preset stations in the memories, you can hear that will stay on each station for about 5 seconds. 2.AUTO MEMORY STORE: Press AMS button long to enter Auto Store mode, this feature will automatically scan the current band and enter up to 6 strongest stations into the 6 preset memories. To stop Auto Store & Scan, press the AMS button again. STATION PRESET BUTTONS (M1-M6) 1.
RDS OPERATIONS AF BUTTON Press this button briefly to switch on or off the AF follow mode, the state of the AF follow mode will be indicated on the LCD by the "AF" icon: Icon Off : AF follow mode off Icon On : AF follow mode on and RDS reception OK Icon Flashing : AF follow mode selected, but no RDS data received When AF follow mode is on, the radio will from time to time measure the signal strength of the alternative frequencies that come with the RDS data.
RDS OPERATIONS OVERVIEW OF THE RDS FUNCTION Radio Data System (RDS) is a broadcasting service that allows FM stations to send additional digital information along with the regular radio program signal. Your car stereo offers you a variety of services. Here are just a few: - PI (Program identification) It is a code that identified RDS stations; it is unique for each station. - PS (PROGRAM Service Name) The name of current station, it is shown on the display.
PROGRAMMABLE OPTIONALS To use this function keep press long SEL Button for few seconds, each time you press this button the mode will move and the functions will shown on the display, turn the encoder volume knob up/ down to set the desires functions ,the function states as following: - TA SEEK, TA ALARM To determine what action will the radio take if the newly tuned station does not receive TP information for 5 seconds. TA SEEK The radio retunes to a different station which contains TP information.
MMC/SD CARD & USB DEVICE OPERATIONS START THE USB DEVICE MODE 1.The USB mini socket is accessible as indicated in picture 1.(P.1) P.1 USB SOCKET 2.Plug in the USB drive / device completely as indicated in picture 2(P.2) and display will show “USB PLAY” to indicate that the USB drive / device is being plugged in correctly & the download has begun. 3.
START THE SD/MMC MODE P.4 P.5 1.Press panel release button to release the front panel.(P.4) 2.The SD/MMC card slot is located on top of the front panel as indicated in (P.5). 3. Insert the SD/MMC card into the card slot in the correct direction until a “CLICK” sound is heard. 4.Close the front panel. 5. The display will show “SD PLAY” to indicate that the SD or MMC card is correctly inserted. Once the SD or MMC card is inserted, the MP3 file will automatically loaded & playback will also start. 6.
MP3 OPERATIONS Notes : - An MP3 directory is shown in this manual as “Directory”, and an MP3 file is shown as “Track”. - Maximum length of file name : 28 characters. - Maximum length of directory : 16 characters. - Maximum number of tracks per disc : 254. - Maximum number of directories per disc : 128. - Sampling Frequencies support : 32KHz, 44 KHz, 48KHz. - Bit Rates support : 64 - 320KHz including VBR. - Supports Multi-Session recording. - Supports CD, CDR and CDRW.
ID3 TAG Press DISPLAY button repeatedly to Display ID3 TAG information.
INSTRUCTION FOR HANDFREE FUNCTION SET UP a. Press panel release button to release the front panel. b. The PAIR button is located on bottom right of the front panel as indicated. c. Press PAIR Button about 4 seconds, the LED indicator twinkle rapidly, and it enters into Pairing Mode (Headset or handsfree profile or both). d. Turn the phone to Bluetooth Menu, then scan Bluetooth set named CAR_AUDIO_HF and enter the connecting password (0000) to connect Bluetooth set after successful scan. e.
The Bluetooth symbol (...) and the connected symbol (< / >) on the mobile phone will be different from one to another. Please refer lo the corresponding specification. The LED turns on when an audio connection exists (e.g. talking) or when it is ringing. When the main unit turns on, if there is a call incoming, it will auto switch to talk state. When you hang up the phone, the main unit will revert to previous state (radio, CD or other mode).
SPECIFICATIONS CD PLAYER System Usable disc Sampling frequency No of quantization bits Frequency Number of channels S/N Ration Compact disc audio system Compact disc 44.1KHz 1bit 5-20,000Hz 2 stereo 70dB RADIO SECTION FM Frequency Range Intermediate Frequency Usable Sensitivity Stereo Separation S/N Ratio 87.5-108 MHz 10.
TROUBLE SHOOTING Before going through the check list, check wiring connection. If any of the problems persist after check list has been made, consult your nearest service dealer. Symptom Cause Solution The car ignition is not on. If the power supply is properly connected to the car accessory terminal, switch the ignition key to “ACC” The fuse is blown. Replace the fuse. Presence of CD disc inside the player. Remove the disc in the player, then put a new one. Inserting the disc in reverse direction.
