128-6710

1 of 6

Model AA-925

Owner's Manual

FEATURES:

w 2 Three Button, RF Transmitters

w Four Channel Code Learning Receiver

w Remote Panic In All Modes

w Built-In Parking Light Output

w LED Status Indicator

w Ignition Door Locking/Unlocking

w Horn Output

OPTIONS:

w Remote Trunk Release

w Remote Power Window Control

w Remote Garage Door Interface

w Remote Engine Starter

w Starter Interrupt

w Siren

w Access Guard / 2 Step Unlock

w Illuminated Entry

Page 1

3 Button Remote Keyless Entry System

With Two Auxiliary Outputs

Released: 3-12-03

Summary of content (6 pages)

PAGE 1
Model AA-925 Owner's Manual 3 Button Remote Keyless Entry System With Two Auxiliary Outputs FEATURES: w 2 Three Button, RF Transmitters w Four Channel Code Learning Receiver w Remote Panic In All Modes w Built-In Parking Light Output w LED Status Indicator w Ignition Door Locking/Unlocking w Horn Output OPTIONS: w Remote Trunk Release w Remote Power Window Control w Remote Garage Door Interface w Remote Engine Starter w Starter Interrupt w Siren w Access Guard / 2 Step Unlock w Illuminated Entry Page 1
PAGE 2
Your Keyless Entry System has many features and available options some of which must be selected at time of installation. For your reference, the list on the back page of this manual shows what features and options have been installed with this particular system. Consult your installing dealer for options that may have been installed and are not listed. REMOTE DOOR LOCKING - ACTIVE 1. Turn the engine off, exit the vehicle and close all doors. 2.
PAGE 3
siren) will chirp twice and the dash mounted LED will turn off. If you have the optional entry illumination circuit installed, the interior light will turn on for 30 seconds or until the ignition key is switched on. Note: If the passive arming mode was selected at time of installation, the dash mounted LED will start flashing rapidly indicating that the system is rearming. Opening any door will suspend the automatic arming. SILENT UNLOCKING 1.
PAGE 4
The system will disarm, allowing the engine to be started and the vehicle to be operated normally. Always remember to move the valet switch to the off position to allow the passive arming and optional starter interrupt features to be operable the next time you park the vehicle. ELIMINATING THE LOCK/UNLOCK CHIRPS You can selectively eliminate the normal lock and unlock chirps by holding the transmitter button slightly longer when locking and unlocking.
PAGE 5
ADDITIONAL REMOTE FUNCTION CHANNEL 3 The system has an additional output (Channel 3), that can be connected to a number of different optional accessories. Some of the more common uses for this channel are: q Remote Engine Start q Remote Window Close q Remote Garage Door Interface To operate the accessory associated with Channel 3, simultaneously press both buttons of your keychain transmitter which were configured and programmed for this function.
PAGE 6
Lock 1 Unlock 2 Lock 1 Unlock 2 Option Button Option Button Lock 1 Unlock 2 Option Button Lock 1 Unlock 2 Option Button Lock 1 Unlock 2 Option Button Lock 1 Unlock 2 Option Button AA-925 SYSTEM FUNCTIONS AT A GLANCE LED INDICATORS: RAPID FLASHING SLOW FLASHING OFF ON SOLID = = = = PASSIVE ARMING ARMED DISARMED VALET MODE OPTIONAL VEHICLE HORN OR SIREN CHIRP INDICATION: 1 CHIRP = LOCK / ARM 2 CHIRPS = UNLOCK / DISARMED CONTINUOUS = PANIC MODE ALARM PARKING LAMP INDICATIONS: 1 FLASH = 2 FL
