VOLUME P IC TU R E SELECT CHANNEL AP VOH802
Important Notice Television Reception It is unlawful in most jurisdictions for a person to drive a motor vehicle which is equipped with a television viewer or screen that is located in the motor vehicle at any point forward of the back of the driver’s seat, or that is visible, directly or indirectly, to the driver while operating the vehicle. In the interest of safety, the VOH802 should never be installed where it will be visible, directly or indirectly, by the operator of the motor vehicle.
FEATURES Congratulations on your purchase of the Audiovox VOH802 drop down TV/Video monitor. The VOH802 has been designed to give you and your family many years of video entertainment in the mobile environment. Please read the directions that follow to familiarize yourself with the product and to ensure that you obtain the best results from your equipment.
FRONT PANEL FEATURE Figure 1 2 1 3 VOLUM E 4 5 PICTURE -4- 6 7 8 SELECT CHANNEL AP
FRONT PANEL FEATURES – See Figure 1 1. Sensor Eye- Allows the remote control to operate the VOH802’s OSD system (On Screen Display), volume to wired headphone jacks (and optional external speakers), and for control of Video Cassette Player and other accessories. 2. Power Button- (Bright red when system is ON, dim when system is OFF). 3. Volume Up/Down- Controls volume to headphone jacks and external speakers if connected. 4.
REMOTE CONTROL OPERATION 1 6 3 BATTERY INSTALLATION 2 Before attempting to operate your Remote Control, install the batteries as described below. 1) Turn the remote control face down. Press down on the ridged area of the battery cover, and slide it off. 2) Install two “AAA” batteries as shown. Make sure that proper polarity (+ or -) is observed. 3) Slide the cover back until it clicks into position.
Remote Controlled TV Functions 1. POWER ON/OFF Press this button to turn the VOH802 on. The channel number or current video source will be displayed on screen, and the picture will appear in a few seconds. Press the button again to turn the VOH802 off. 2. DIRECT ACCESS (0-9) BUTTONS Use these buttons to make a direct channel selection. The channel number chosen will be displayed on the screen for about 4 seconds. The direct access is carried out with 0-9 keys (0-99CH).
. AUTO MEMORY BUTTON When the AUTO MEMORY BUTTON is depressed, all channels in TV mode are searched and tuned; all channels with video signals detected are automatically stored. Please refer to page 2 for more information on TV reception. 9. SKIP/SEARCH BUTTON This button selects between SKIP and SEARCH mode. In “SKIP mode” the TV only stops on channels that are programmed into memory when the CHANNEL UP/DOWN buttons are used. When the SKIP is turned off, the TV will only stop on all active channels. 10.
CHANNEL TUNING SETUP In order to easily access all available channels, it may be necessary to perform channel auto-programming whenever the vehicle’s geographic location has changed, i.e. city to city, weak signal area. 1. Press the AUTO MEMORY button on the remote control unit or the AUTO PROGRAM button on the flip down video unit. You will see the TV cycle through all it’s channels. The built-in microprocessor will automatically note each channel that is actively broadcasting in your area. 2.
Remote Sensor TURNING THE VOH802 ON OR OFF 1. Sliding the screen release lock forward viewing will unlock the LCD screen and it will drop down slightly. (Pivot the screen downward until a comfortable angle is reached). After the unit has been turned on and displaying a picture, adjustment to the viewing angle can be made by pivoting the screen to optimize the picture quality. The internal friction detent will hold the screen in position while the system is in use. 2.
OPTIONAL ACCESSORIES Auxiliary A/V Stereo Inputs Jack Wireless Headphones The VOH802 may be equipped with an auxiliary A/V stereo input connector (optional). These inputs are provided to facilitate the temporary connection of optional audio/video equipment, such as a camcorder or video game system. To play a source with these inputs, an RCA patch cord is required to connect the audio/video signals to their respective jacks.
Audiovox Video Cassette Player (Aux Video 1) Wired FM Modulator (P/N 0190730) Your video system may be equipped with an RF modulator, that allows you to listen to the VOH802’s audio signal by tuning your vehicle’s radio to the selected frequency, (88.7 or 89.1- check with your installer) and tuning on the remote mounted RF modulator switch. (In most cases this toggle switch will be located underneath the driver’s side of the dash, check with your installer for the exact location.
TYPICAL SYSTEM CONNECTIONS Antenna To FM Transmitter V1 VCP PIN 1 – Power/Red PIN 2 – Power GND/Black V2 DVD Speaker or Headphone connection PIN 3 – Audio(L)Out/Grey PIN 4 – Audio GND/Black PIN 5 – Audio(R)Out /Green Accessory Harness Yellow (Video out) Red (Audio Out R) White (Audio Out L) 2 PIN IR Connector Yellow RCA(Video) 4 PIN Power Connector White RCA(Audio Left) Red RCA(Audio Right) -13-
Troubleshooting PROBLEM Poor TV Reception SOLUTION • • • Poor radio reception (FM modulator installed) • • • IR sensor inoperative Specifications • • • Perform auto programming of the tuner Verify antenna condition. NOTE: Due to the nature of TV signals, vehicle motion, direction the vehicle is facing, distance from the transmitter, nearby surroundings and weather may adversely affect TV reception.
© Copyright 2000 Audiovox Corp. 150 Marcus Blvd.
