INSTALLATION AND OPERATION MANUAL XDS SERIES FULL RANGE PASSIVE LOUDSPEAKERS XDS8 XDS10 XDS12 SUBWOOFERS XDS115 XDS212
IMPORTANT SAFETY INFORMATION PRÉCAUTIONS DURANT UTILISATION 1. Read these instructions. 1. LISEZ ces instructions. 2. Keep these instructions. 2. Tenez ces instructions. 3. Heed all warnings. 3. Notez tous les avertissements. 4. Follow all instructions. 4. Suivez toutes les avertissements. 5. Do not use this apparatus near water. 5. N’utilisez pas ce produit près de l’eau (la piscine, la plage, le lac, etc.). 6. Clean only with dry cloth. 6. Nettoyez seulement avec une étoffe sèche.
INTRODUCTION AND CONTENTS XDS SERIES The XDS range of speakers includes 8”, 10” and 12” models all with high quality compression drivers and two subwoofer models with a single 15” or dual 12”. The XDS range of speakers is perfect for driveway or corporate hire as well as live sound installations.
FRONT PANEL XDS212 shown here XDS10 shown here XDS10 2 Way Full Range Speaker Made in China SN: 1 2 Full range enclosures 1 High Frequency Driver 1 Subwoofers Two passive subwoofers are available in the XDS range, a ported/front loaded single 15” subwoofer and a dual 12” bandpass subwoofer. A single horn loaded compression driver. XDS8 1 x 1.35”. Flare: 100º x 100º non-rotatable XDS10 1 x 1.35”. Flare: 50-100º x 50º rotatable XDS12 1.7”.
REAR PANEL XDS212 shown here XDS10 shown here XDS212 Dual 12” Subwoofer Frequency Response (-3dB) Sensitivity (dB 1W 1M) Impedance Recommended Max Power (Program) 50Hz–180Hz 99 dB 8 Ohm 600W Made in China SN: XDS10 2 Way Full Range Speaker Made in China SN: 1 2 1 Speaker Input 1 1 Speaker Input Speaker inputs are via a pair of 4pole twist lock connectors (Neutrik speakON or compatible) wired in parallel.
MOUNTING Wall Mount Brackets Subwoofers A number of wall mount options are available for the XDS speaker range. The XDS series Subwoofers are designed to be free standing for floor mounted installation. The wall mount U brackets permit speaker mounting in either horizontal or vertical orientation. The brackets are supplied with enclosure mounting plates to replace the standard pole mount and blank plate fitted to the speakers as standard.
MOUNTING When mounting via a bracket or eyebolts the following must be considered. Suspending with Eyebolts The mounting of a permanently installed speaker may be dangerous unless undertaken by a qualified professional with the required experience. The XDS range of speakers provide a number of secured mounting points for use with M10 eye bolts. Walls and mounting surfaces must be capable of supporting the speaker and bracketry in a safe and secure manner.
ACCESSORIES XDS8 PART DESCRIPTION XDS8UB U bracket for XDS8 XDSWMB Wall mounting bracket for XDS8/10/12 AMISLSB1 Wall mount bracket ATC303 Tripod speaker stand ATC304 Heavy duty tripod speaker stand ATC305 Winch up speaker stand XDS10 PART DESCRIPTION XDS10UB U bracket for XDS10 XDSWMB Wall mounting bracket for XDS8/10/12 AMISLSB1 Wall mount bracket ATC303 Tripod speaker stand ATC304 Heavy duty tripod speaker stand ATC305 Winch up speaker stand XDS12 PART DESCRIPTION XDS12UB
DIMENSIONS 293.00 mm (11.5”) 284.00 mm (11.2”) 408.00 mm (16.1”) XDS8 XDS8 2 Way Full Range Speaker Made in China SN: 348.60 mm (13.7”) 328.00 mm (12.9”) 502.00 mm (19.8”) XDS10 XDS10 2 Way Full Range Speaker Made in China SN: 396.00 mm (15.6”) 620.00 mm (24.4”) XDS12 SN: XDS SERIES INSTALLATION AND OPERATION MANUAL 480.00 mm (18.
DIMENSIONS XDS115 600.00 mm (23.6”) 650.00 mm (25.6”) 512.00 mm (20.1”) XDS115 Single 15” Subwoofer Frequency Response (-3dB) 35Hz–500Hz Sensitivity (dB 1W 1M) 96 dB Impedance 8 Ohm Recommended Max Power (Program) 300W Made in China SN: XDS212 600.00 mm (23.6”) 680.00 mm (26.8”) 512.00 mm (20.
SPECIFICATIONS XDS8 XDS10 XDS12 Impedance (Nominal) 8 Ohms 8 Ohms 8 Ohms 100 Watts 250 Watts 300 Watts Sensitivty (1 W / 1 M) 92 dB 94 dB 96 dB Calculated Max SPL 112 dB 118 dB 121 dB 100º x 100º non-rotatable 50-100º x 50º rotatable 80º x 50º rotatable Frequency Response (-3dB) 80 Hz - 20 kHz 55 Hz - 20 kHz 50 Hz - 18 kHz Frequency Response (-10dB) 70 Hz - 20 kHz 50 Hz - 20 kHz 45 Hz - 20 kHz Power (Continuous) Dispersion (-6 dB Points) (H x V) Connection Components
ENGINEERED BY AUSTRALIAN MONITOR Address: 1 Clyde Street, Silverwater, Sydney NSW 2128 Australia. Private Bag 149, Silverwater NSW 1811 ACN 007 573 417 Website: www.australianmonitor.com.au International enquiries email: international@australianmonitor.com.au DISTRIBUTED IN AUSTRALIA AND NEW ZEALAND BY HILLS SVL www.hillssvl.com.au NSW P: 02 9647 1411 E: nsw@hillssvl.com.au QLD P: 07 3852 1312 E: qld@hillssvl.com.au ACT P: 02 6260 4544 E: act@hillssvl.com.au WA P: 08 9204 0200 E: wa@hillssvl.com.
