 CCM -- Comprehensive Component Monitor
 EGR – EGR System Monitor
 HCCAT -- NMHC Catalyst Monitor
 NCAT -- NOx Aftertreatment Monitor
 BP -- Boost Pressure System Monitor
 EGS -- Exhaust Gas Sensor Monitor
 PM -- PM Filter Monitor
Figure 5.35
5) If the vehicle supports readiness test of “This Drive Cycle”, a
screen of the following displays:
Figure 5.36
6) The LEDs and audio tone corresponding to different monitor
status will be activated as below.
…………Since DTCs Cleared 1
MIL OFF
MIS OK
FUEL OK ?
CCM OK
CAT INC
HCAT N/A
…………..This Drive Cycle 1.
MIL OFF
MIS OK
FUEL N/A ?
CCM OK
CAT INC
HCAT N/A
