RF-302 OPERATION INSTRUCTIONS
Congratulations on your purchase of the RF-302 vehicle security system. AutoPage, Inc. is one of the companies with the longest history and experience in vehicle security in the United States and a wholly owned subsidiary of Iwata Electric Co., of Tokyo, Japan. Iwata has been an industry leader for 40 years, establishing a reputation for ingenuity in its engineering capability and innovative communication products.
RF-302 RF-302 OPERATION INSTRUCTIONS A. REMOTE CONTROL TRANSMITTER OPERATION 1. ARM/DISARM TO ARM THE RF-302 Press the ON/OFF button once to arm. The siren will chirp one (1) time, the lights will flash, and all doors will lock. (*) TO DISARM THE RF-302 Press the ON/OFF button once to disarm. The siren will chirp two (2) times, the lights will flash, and all doors will unlock.
RF-302 3. PANIC FUNCTION The RF-302 remote control may be used as a remote panic switch to trigger the siren in cases of emergency. To activate the PANIC FUNCTION press and hold the ON/OFF button on the remote transmitter for a minimum of 3 seconds. The siren will sound. To stop the PANIC FUNCTION press the ON/OFF button on the transmitter. 4. THE PRE-WARNING SENSOR CIRCUIT (If installed) The RF-302 offers an option to pre-warn possible violators with siren chirps before triggering the alarm.
RF-302 To replace the battery, carefully remove the case screw located at the end of the remote where the key ring attaches to the case. Use a small blade Phillips screwdriver. Before removing the battery note the + direction of its terminals. Install the new battery exactly the same, using caution so as not to bend, or otherwise damage the battery contacts. Replace the case cover and carefully tighten the screw. Do not over-tighten the screw! Test the transmitter to insure it arms and disarms the alarm.
RF-302 NOTE: Both VALET and OVERRIDE functions are performed from the same switch. 1. OVERRIDE FUNCTION The OVERRIDE FUNCTION may be used if the RF-302 remote is lost or inoperative. To operate the OVERRIDE FUNCTION, enter the vehicle (siren will sound); switch the vehicle ignition to ON. Move the VALET/OVERRIDE switch to ON; then OFF; the siren will stop. The RF302 will be disarmed. Quickly replace or service the remote transmitter to insure continued vehicle protection. 2.
RF-302 1. PASSIVE ARMING If you choose the PASSIVE (automatic) mode, the system must be operated as below. 1. Switch OFF vehicle ignition, exit vehicle, and be sure all protected openings are closed. 2. The LED STATUS INDICATOR will begin fast flashing and the passive arming timer will begin counting down. 3. If you re-open the exit the LED will stop flashing. 4. Close the exit, and the LED will start flashing again. 5. The RF-302 will count down for 30 seconds.
RF-302 Approach the vehicle and press the ON/OFF remote transmitter button. The siren will chirp 2 times and the lights will flash to indicate the RF302 is disarmed. G. AUTOMATIC RE-ARMING The RF-302 is equipped with an automatic re-arming circuit that will return the alarm to a fully armed state if a door is not opened within 60 seconds after disarming. This automatic re-arming circuit can be eliminated at the time of installation. H.
RF-302 1. Open any door or other protected opening. The siren will sound instantly, and the lights will flash. 2. If optional sensors have been installed, arm the RF-302 and test according to the directions of the particular sensor installed. If triggered in the armed condition, the RF-302 will sound its siren and flash the lights for 60 seconds; then it will stop and automatically reset and rearm. If the violation continues, the alarm will sound and lights will flash for two 60 second cycles. K.
RF-302 4. Turn the ignition switch "ON/OFF", "ON/OFF". The siren will chirp one (1) time. You are now in the programming mode. 5. Press the ON/OFF button on one of the remote transmitters until the alarm siren responds with a confirming chirp. The first transmitter is now programmed. 6. Within five (5) seconds, press the ON/OFF button on the second transmitter until the alarm siren responds with a confirming chirp. The second transmitter is now programmed.
RF-302 Enter the programming mode on vehicle #1 and push the ON/OFF button on the transmitter for Vehicle #1. The alarm siren will respond with a confirming chirp. Within five (5) seconds, push the AUX. button on the transmitter for Vehicle #2. The alarm siren will respond with a confirming chirp. Both transmitters are now programmed to Vehicle #1. VEHICLE #2 Enter the programming mode on Vehicle #2 and push the AUX. button on the first transmitter used for Vehicle #1.
RF-302 TRANSMITTER #3 AUX. BUTTON ON/OFF BUTTON BOTH BUTTONS AUX. BUTTON BOTH BUTTONS ON/OFF BUTTON BOTH BUTTONS AUX.
RF-302 AUTOPAGE ALARM ACCESSORIES AP-4000DX Paging System Vehicle security paging was originated by AutoPage over 18 years ago. The AP4000DX is our latest version providing a full four watts of output power to signal a handsome belt-clip paging receiver indicating your RF-302 has been triggered, even if you cannot hear the siren. RS-32 Dual Stage Perimeter Protection Sensor The RS-32 uses a microwave frequency to detect field disturbance within a contained area.
RF-302 sensors, the SIS-10 has a LED and potentiometer for easy sensitivity adjustment. MSEN-KIT The MSEN-KIT includes two pre-wired Micro Resonance Sensors and a special triggering amplifier. These special sensors are designed to be mounted within the vehicle door or on the door post near the latching mechanism that keeps the door closed.
LIMITED LIFETIME WARRANTY PROVISIONS (U.S. and Continental U.S. Only) 1. AutoPage, Inc. WARRANTS that this new unit has been thoroughly inspected and tested at the factory prior to delivery. Your AutoPage equipment is guaranteed for "life" to the origin al purchaser/user of the equipment under the following conditions: If the product proves defective (according to AutoPage's testing) within the first year, the defective unit may be exchanged or repaired free of charge.
RF-302 LIMITED TO ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. 7 AutoPage shall not be liable, under the foregoing WARRANTIES or otherwise, for: Any personal injury of any kind to the purchaser, its employees or agents or anyone else whomsoever resulting directly or indirectly from the use or presence of the equipment or parts; Consequential damages of any kind; Any inability of the purchaser to use the equipment.
This WARRANTY CARD is for your record. However, AutoPage reserves the right to request you to submit this WARRANTY CARD which must have complete information to receive warranty service. Please keep this card in a secured place.
DATE SERVICE COMPLETED 13
