H.3.10.S.3.20 DOC:.3.20 August 20, 2003 DS CA Manufactured in Canada by Autostart

AUTOMATIC TRANSMISSION MULTI-CHANNEL REMOTE STARTER SYSTEM

AS-1414/ AS-1424

User Guide

Transmitter Part Number and Module Serial

Number..............................................................2

Introduction .......................................................2

Basic Remote Operation ...................................2

Remote-starting Your Vehicle ...........................3

Vehicle Presets.............................................3

Driving Off.....................................................3

Idle Mode ......................................................3

Valet Mode ........................................................3

Ignition Valet .................................................3

Valet Mode Using the Valet Button...............4

Cold Weather Mode......................................4

Advanced Features...........................................4

Remote Door Locks ......................................4

Arming the Starter Kill...................................5

Installer-programmable Features......................5

Remote Door Locks Option ..........................5

Ignition-controlled Door Locks Option ..........5

Secure Lock Option ...................................... 5

Remote Trunk Release Option ..................... 5

Engine Run Time ..........................................5

Starter Kill / Anti-Grind ..................................6

Troubleshooting Poor Transmitting Range Issues

..........................................................................6

Please Note:

x The AS-1414 system is equipped with one 4-

button multi-channel Transmitter and the LED

is optional.

x The AS-1424 system is equipped with two 4-

button multi-channel Transmitters as well as

an LED.

Summary of content (6 pages)

PAGE 1
AUTOMATIC TRANSMISSION MULTI-CHANNEL REMOTE STARTER SYSTEM AS-1414/ AS-1424 User Guide Transmitter Part Number and Module Serial Number..............................................................2 Introduction .......................................................2 Basic Remote Operation ...................................2 Remote-starting Your Vehicle ...........................3 Vehicle Presets .............................................3 Driving Off ................................................
PAGE 2
Transmitter Part Number and Module Serial Number Transmitter Part Number: ASTR-204 The installer is to write in the boxes below the Module’s serial number and the location of the Valet Switch (If the Valet switch is installed). Module Serial Number: Your Valet Switch is located: Introduction This Module is a state-of-the-art remote car starter system.
PAGE 3
Remote-starting Your Vehicle Press the START/STOP button for approx. 1 second. The parking lights will come ON, informing you that the unit has received your signal. Approx. 5 seconds later, the engine will start. The parking lights will remain ON during the pre-programmed run time. If the vehicle doesn’t start the first time, the system will shut down, wait a few seconds, and try to start the engine again. It will try to start the engine 3 times before giving up.
PAGE 4
To ENTER Valet Mode 1. With the key in the Ignition switch, turn the key to the ON (RUN/IGNITION) and then OFF positions 5 times within 10 seconds. 2. The Parking Light will flash 3 times indicating the Module is now in Valet Mode. The LED will turn ON solid. To EXIT Valet Mode 1. With the key in the Ignition switch, turn the key to the ON (RUN/IGNITION) and then OFF positions 5 times within 10 seconds. 2. The Parking Light will flash twice indicating the Module is now out of Valet Mode.
PAGE 5
Arming the Starter Kill If installed, the Starter Kill can be programmed to arm in Active Mode (will not arm automatically) or in Passive Mode (will arm automatically). x To disarm the Starter Kill in Active or Passive Mode, press the UNLOCK button on the transmitter. The parking lights will flash twice. (If Remote Door Locks were installed, this will also unlock the doors.) In Passive Mode, the system will automatically rearm 1 or 3 minutes after the doors were unlocked.
PAGE 6
Starter Kill / Anti-Grind This added security feature will immobilize your vehicle when the system is armed (LOCKED). If your Module was installed with the Starter Kill option, you will not be able to start your vehicle with the key unless the system has been disarmed first (UNLOCKED). The Starter Kill option can be programmed to be ACTIVE (will not arm automatically) or PASSIVE (will arm automatically). In PASSIVE Mode, your installer can program it to arm automatically in 1 or 3 minutes.
