USER’S GUIDE Installation, Operation, and Maintenance for your product. Built-In Beverage Refrigerator Model – ABR241SGRH / ABR241SGLH www.avallon.com V2.
Important Safety Information Improper handling can cause serious damage to the Avallon beverage refrigerator and/or injury to the user. This beverage refrigerator is designed for domestic indoor use only. Do not use the unit for industrial or commercial use. Any other use may invalidate the warranty. Please review the rating label located on the rear panel of the unit for electrical and other technical data related to this unit. The unit must be used in a properly grounded wall outlet.
GENERAL SAFETY • • • • • • • • • • • • • • • To prevent back and other types of injuries, use at least two people to move and install the beverage refrigerator. This appliance is not intended for use by persons, including children, with reduced physical, sensory, or mental capabilities, unless they have been given supervision or instruction concerning the use of the appliance by the person(s) responsible for their safety.
Table of Contents Important Safety Information .............................................................................................................................................. ii Table of Contents................................................................................................................................................................ iv Introduction..............................................................................................................................
First Time Operating Instructions: Before use, make sure all packaging labels and materials are removed from the unit. Be sure to keep track of all included parts and pieces before discarding packaging materials. It is advised that you keep the original box and packaging materials in case you need to move or ship the appliance in the future. Allow the unit to stand for at least 24 hours before you use it; this allows the cooling components time to settle from transit.
Introduction Thank you for purchasing your Avallon beverage refrigerator. Avallon is dedicated to developing products that will enhance your lifestyle with superior quality and distinctive features. Please visit www.avallon.com for more information on your product and other Avallon products. This manual contains important information regarding the proper installation, use, and maintenance of your beverage refrigerator.
Parts Identification Full View Empty View 2
Carbon Filter A built-in carbon filter protects your beverages by acting as a natural barrier against harmful odors. Internal Fan This is an air-cooled unit equipped with an internal fan that maintains a consistent internal temperature. Note: The carbon filter should be replaced every 3-6 months depending on the unit’s exposure level to odor. If the unit is placed in a kitchen, regular replacement every three (3) months is ideal.
TYPES OF INSTALLATION: This beverage refrigerator has been designed for free-standing or built-in installation. In every case, there must be adequate ventilation and access for service. Free-standing Installation A free-standing installation will allow you to install the beverage refrigerator in almost any place you desire. You must follow the stated instructions for electrical requirements and leveling the beverage refrigerator.
Installation Clearance Requirements: When installing the beverage refrigerator under a counter, follow the recommended spacing dimensions shown. • To ensure proper service access and ventilation, allow between 1 - 2 inches of clearance at the back as shown in the diagram. • The installation should allow the unit to be pulled forward for servicing, if necessary.
RECOMMENDED GROUNDING METHOD: For your personal safety, this appliance must be grounded. It is equipped with a power supply cord having a 3-prong grounding plug. To minimize possible shock hazard, the cord must be plugged into a mating 3pronged wall socket, and grounded in accordance with the National Electrical Code and local codes and ordinances.
INSTALLING THE SHELVES: 1. 2. 3. 4. Open the door completely. Ensure that the metal guide posts are attached to the rear of the shelf. Tilt the shelf 45° counterclockwise. The metal guide post on your left side should rest on the shelf track. Gently push the shelf back towards the rear of the unit until the right side metal guide post meets the vertical indentation in the plastic interior cabinet. 5. Gently set the right side of the shelf down on the shelf track.
Operation INSTALLATION CHECK-LIST BEFORE OPERATION: 1. Have all packing materials and tape been removed from the interior and exterior of the beverage refrigerator? 2. Have the installation instructions been followed, including connecting the machine to electricity? 3. Has proper grounding been installed for the beverage refrigerator? 4. Has the machine been leveled? 5. Is the beverage refrigerator in a site where the ambient temperature is between 50° F and 90° F all year round? 6.
Note: Pressing and holding the increase and decrease temperature buttons at the same time will switch the temperature display from °F to °C. Tip: If you powered the unit off, please wait at least five (5) minutes before powering it back on. Warning: Allow at least 24 hours for your beverage refrigerator to run before storing your beverages and to allow the temperature to acclimate. Whether your beverage refrigerator can reach the actual set temperature depends on the ambient environmental conditions.
Defrosting The wine refrigerator will automatically defrost under most temperature settings and ambient conditions. However, on colder settings, some frost may build up. Additionally, under more humid ambient conditions, more frost may build up. Keep the door closed as much as possible and avoid opening the door unnecessarily to minimize frost build-up. If frost is preventing the door from closing properly, you may need to power the unit off until the frost melts. Use a soft absorbent towel to dry the unit.
Preparing Your Beverage Refrigerator for Storage If the beverage refrigerator will not be used for a long time, or is to be moved to another place, it will be necessary to defrost the unit and dry the interior. 1. Disconnect the refrigerator from the power supply by removing the power plug from the wall socket. 2. Leave the door open to allow for air circulation and to prevent mold, mildew, and unpleasant smells. 3. Once the interior is dry and clean the unit will be ready for storage.
ISSUE The beverage refrigerator will not reach the desired temperature. POSSIBLE CAUSE The refrigerator has restricted air flow due to too much storage. The refrigerator is placed too close to a heat source. The refrigerator does not have sufficient ventilation. The door is opened too frequently or for long periods of time. The beverage refrigerator is making strange noises. Certain sounds are normal The unit is not level or is touching another appliance.
Specifications DESCRIPTION OF PRODUCT Built-In Beverage Refrigerator MODEL ABR241SGRH / ABR241SGLH VOLTAGE / FREQUENCY AC 115 / 60 Hz AMPERAGE 1.5 A INPUT POWER 120 W COLOR Black Cabinet with Stainless Steel Door STORAGE CAPACITY 140 Cans* REFRIGERANT R600a, 1.4 oz. TEMPERATURE RANGE 34° F to 50° F DIMENSIONS (HEIGHT X WIDTH X DEPTH) 34 1/8” X 23 13/16” X 25 5/8” ** WEIGHT 114 Pounds Note: Technical data and performance information are provided for reference only.
Avallon Product Warranty 14
