Use and Care Guide

4
Built-in Installation
A recessed installation will allow you to install the wine and beverage cooler under a counter or in a
kitchen cabinet provided the clearance space requirements around the wine and beverage cooler are
followed. It is necessary to allow adequate ventilation space around the unit (make sure there is at least
some ventilation room for the back of the unit). The following additional items must be observed:
1. Place the wine and beverage refrigerator in front of the installation location.
2. Adjust the feet and place the unit flat on the floor or on a platform depending on your installation
requirements.
3. If the electrical outlet for the wine and beverage refrigerator is behind the cabinet, plug in the wine
and beverage refrigerator.
4. Push the wine and beverage refrigerator into position.
5.
Installation Clearance Requirements:
When installing the refrigerator under a counter, follow the recommended spacing dimensions shown.
• To ensure proper service access and ventilation, allow between 2 - 3 inches of clearance at the back as shown in
the diagram.
• The installation should allow for 2 inches on any side with a wall that extends past the front of the unit so the
doors will open properly with the handles installed.
• The installation should allow the unit to be pulled forward for servicing, if necessary.
• A standard electrical supply (115 VAC only, 60 Hz), properly grounded in accordance with National Electrical Code
and local codes and ordinances, is required.
Warning: DO NOT install the wine and beverage refrigerator behind a closed cabinet door.
Important: Once you are ready to install the unit in a cabinet or directly on the floor, you must adjust the
feet to level the wine and beverage refrigerator.
