BFC-15W9 15.6” Multifunctional Full Flat Multi-Touch Panel Computer Quick Reference Guide 1st Ed –09 October 2014 Copyright Notice Copyright 2014 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No.
BFC-15W9 FCC Statement THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE. (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
Quick Reference Guide Content 1. Getting Started ............................................................................................................ 4 1.1 1.2 1.3 1.4 1.4.1 1.5 1.5.1 2. Safety Precautions ................................................................................................ 4 Packing List ........................................................................................................... 4 System Specifications .................................................
BFC-15W9 1. Getting Started 1.1 Safety Precautions Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis. Caution! Always ground yourself to remove any static charge before touching the CPU card. Modern electronic devices are very sensitive to static electric charges.
Quick Reference Guide 1.3 System Specifications Component Mother Board EBM-BYT CPU Onboard Intel® Atom Quad-Core J1900 2.0GHz with Integrated Chipset Memory One 204-pin DDR3L SODIMM Socket Supports Up to 8GB DDR3L 1066/1333 SDRAM Adapter +12 Vdc / 5 A (60W) Wireless LAN Optional USB/MPCIe WiFi module Hard Disk Drive Optional 2.5" SATA HDD Solid State Drive Optional 2.5" SATA SSD Other Storage Device Optional mSATA LCD Panel 15.
BFC-15W9 6 Vibration Test Follow standard ones Mechanical Shock Test Follow standard ones Drop Test Follow standard ones Operating Temperature 0 to 40°C Operating Humidity 5%~90% relative humidity, non-condensing Storage Temperature -10 to 50°C BFC-15W9 Quick Reference Guide
Quick Reference Guide 1.4 System Overview 1.4.1 Rear View Connectors Label Function Note COM1 External Serial Port 1 connector DB-9 male connector HDMI HDMI connector LAN1/2 RJ-45 Ethernet 1/2 Power System power switch DC IN DC Power-in connector RESET Reset button HDD HDD LED PWR Power LED USB USB 2.0 connector x 1 USB 3.
BFC-15W9 1.5 System Dimensions 1.5.
Quick Reference Guide 2. Hardware Configuration For advanced information, please refer to: 1- EBM-BYT Quick Installation Guide or User’s Manual Note: If you need more information, please visit our website: http://www.avalue.com.
BFC-15W9 2.1 BFC-15W9 connector mapping 2.1.
Quick Reference Guide 2.2 Installing Hard Disk & Memory (BFC-15W9) Step1. Unfasten 6 screws from the case to take off the top chassis. Step2. Remove the top chassis.
BFC-15W9 Step3. Unfasten 4 screws of the HDD bracket and take it off. Step4. Remove the SODIMM from the memory socket.
