EBM-CX700 5.25" VIA CX700 Mini Module with DDR2 SO-DIMM, VGA, LCD, USB, COM & DIO Quick Installation Guide 1st Ed – 7 December 2007 Copyright Notice Copyright © 2007 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No.
EBM-CX700 Series 1. Getting Started 1.1 Safety Precautions Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis. Caution! Always ground yourself to remove any static charge before touching the CPU card.
Quick Installation Guide 2. Hardware Configuration Note: For further product information, please visit our website: http://www.avalue.com.tw For further update information, please visit our technical support site: http://www.avalue.com.tw/support For further sales issue, please e-mail to us: sales@avalue.com.
EBM-CX700 Series 2.
Quick Installation Guide 2.2 Jumper and Connector List You can configure your board to match the needs of your application by setting jumpers. A jumper is the simplest kind of electric switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them. To “close” a jumper you connect the pins with the clip. To “open” a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1, 2, and 3.
EBM-CX700 Series Connectors Label Function Note CN1 Audio connector 6 x 2 header, pitch 2.0mm COM1 Serial Port 1 connector D-sub 15-pin, Female COM2 Serial Port 2 connector 5 x 2 header, pitch 2.0mm DIMM1 DDR2 SODIMM 1.8V 200-pin DDR2 SODIMM socket FAN1 & 2 Fan connector 2 x 1 wafer, pitch 2.54mm IDE1 Primary IDE connector 22 x 2 header, pitch 2.0mm J2 Audio Connector Phone Jack JBKL1 LCD inverter connector 5 x 1 header, pitch 2.
Quick Installation Guide 2.3 Setting Jumpers & Connectors 2.3.1 Clear CMOS (J1) Protect * Clear CMOS * Default 2.3.2 AT/ATX Power Select (JP2, JP1) AT JP1 JP2 ATX* JP1 Signal PIN PWR_BN 1 GND 2 * Default Note: JP1 is available in ATX mode only.
EBM-CX700 Series 2.3.3 2.3.
Quick Installation Guide 2.3.5 LCD Inverter Connector (JBKL1) Signal PIN +12V 1 GND 2 ENBKL 3 VR 4 +5V 5 Note: For inverters with adjustable Backlight function, it is possible to control the LCD brightness through the VR signal controlled by JP5. Please see the JP5 section for detailed circuitry information. 2.3.5.1 Signal Description – LCD Inverter Connector (JBKL1) Signal Signal Description VR Vadj = 0.75V ~ 4.25V (Recommended: 4.
EBM-CX700 Series 2.3.6 2.3.
Quick Installation Guide 2.3.8 2.3.9 IrDA Connector (JIR1) Signal PIN +5V 1 NC 2 IRRX 3 GND 4 IRTX 5 LVDS & DVI Connector (JLVDS1) Signal PIN PIN Signal +5V 2 1 +3.3V +5V 4 3 +3.
EBM-CX700 Series 2.3.10 LED Indicator Connector (JP3) Signal 2.3.11 PIN PIN Signal GND 1 2 +5V DHDLED 3 4 +5V DACT_LAN1 5 6 +5VSUS DACT_LAN2 7 8 +5VSUS LCD Backlight Brightness Adjustment Connector (JP5) Signal PIN +5V 1 VR 2 GND 3 VCC JVR1 1 JBKL1 pin 4 2 3 Variation Resistor (Recommended: 4.
Quick Installation Guide 2.3.12 TV Connector (JTV1) Signal PIN PIN Signal GND 2 1 CVBS/Pb C/Pr 4 3 Y GND 6 5 GND DAC Output Mode AV-signal CVBS S-video Y HDTV 2.3.
EBM-CX700 Series 2.3.14 2.3.
Quick Installation Guide 1.4 Audio / USB Daughter Board User’s Guide 1.4.1 Jumper and Connector Layout 2.4.2 Connector List Connectors Label Function Note DJP1 USB 1.1/2.0 connector 5 x 2 header, pitch 2.0mm DJP2 Audio connector 6 x 2 header, pitch 2.0mm DJP3 Power & HDD & LAN LED indicator connector 4 x 2 header, pitch 2.0mm DJP4 Power button connector 2 x 1 header, pitch 2.0mm DLI1 Line in connector Phone Jack DLO1 Line out connector 2 x 2 header, pitch 2.
EBM-CX700 Series 2.4.3 Setting Connector USB 1.1/2.0 Connector 1 (DJP1) Signal PIN PIN Audio Connector (DJP2) Signal Signal PIN PIN Signal +5V 1 2 GND LINEOUT_R 1 2 LINEOUT _L D1- 3 4 GND GND 3 4 GND D1+ 5 6 D2+ LIN_R 5 6 LIN_L GND 7 8 D2- Mic In 7 8 Mic Bais GND 9 10 +5V LINEOUT_JD 9 10 LINEIN_JD MIC_JD 11 12 GND Note: Wrong USB cable configuration with your USB devices might cause your USB devices damaged.
