EMX-QM77 Intel® QM77 with Core™ i7 / i5 / i3 Mini-ITX Motherboard Quick Installation Guide 1st Ed – 23 July 2012 Part No: E2017EMXQ00R
EMX-QM77 FCC Statement THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE. (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
Quick Installation Guide Life Support Policy Avalue Technology’s PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN LIFE SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL OF Avalue Technology Inc. As used herein: 1.
EMX-QM77 and ready to give you the support you need to get the most from your Avalue’s products. In fact, most problems reported are minor and are able to be easily solved over the phone. In addition, free technical support is available from Avalue’s engineers every business day. We are always ready to give advice on application requirements or specific information on the installation and operation of any of our products. Please do not hesitate to call or e-mail us.
Quick Installation Guide 1. Getting Started 1.1 Safety Precautions Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis. Caution! Always ground yourself to remove any static charge before touching the CPU card.
EMX-QM77 2.
Quick Installation Guide 2.
EMX-QM77 2.2 Jumper and Connector List You can configure your board to match the needs of your application by setting jumpers. A jumper is the simplest kind of electric switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them. To “close” a jumper you connect the pins with the clip. To “open” a jumper you remove the clip. Sometimes a jumper will have three pins, labeled 1, 2, and 3.
Quick Installation Guide Smart Fan Control Yes Display Chipset Intel GMA HD 4000 /2500 (22nm) , 3000/2000(32nm) Display Memory Shared Memory, up to 256MB Dual Display VGA + LVDS, VGA + HDMI, VGA + DVI, LVDS + HDMI, LVDS + DVI, HDMI + DVI VGA Onboard, supports max resolution 2048 x 1536 (@75Hz) LVDS Onboard 24-bit LVDS, supports max resolution 1920 x 1200 HDMI Onboard HDMI 1.
EMX-QM77 SYS_FAN1 System Fan 1.GND 2.SYSFAN1_VCC(PWM) 3.SYSFAN1_IO Connector Connectors Label Function COM2 Serial Port COM3 Connector F_PANEL1 Intel Front Note 1.DCD 2.RXD 3.TXD 4.DTR 5.GND 1.HDDLED+ 2.POWERLED+ 3.HDDLED4.POWERLED5.GND 6.PWSWITCH 7.RESET 8.GND 9.NC Panel connector JLVDS 6.DSR 7.RTS 8.CTS 9.RI/PWR 24-bit LVDS Connector 39.VDD(+12V) 37.GND 40.VDD(+12V) 38.GND 35.LVDS_B_CK- 36.LVDS_A_CK- 33.LVDS_B_CK+ 34.LVDS_A_CK+ 31.GND 32.GND 29.LVDS_B3- 30.LVDS_B2- 27.
Quick Installation Guide JBKL LCD Inverter Connector JLPC1 FPAUD1 LPC Connector 1.NC 3.LPC_AD3 5.LPC_AD1 7.LPC_FRAME# 9. 11.CLK33M_LPC Audio Mic.-In 10.LINE_JD 8.NC 6.MIC2_JD 4.PRESENSE 2.GND & Line-Out Connector JGPIO1 GPIO Connector SPDIF_OUT SPDIF OUT Connector USB56 USB 2.0 Connector USB78 USB910 USB1112 KBMS2 1.+12V 2.GND 3.ENBKL 4.VR 5.+5V KB/Mouse Connector 1.SIO_GPIO0 3.SIO_GPIO1 5.SIO_GPIO2 7.SIO_GPIO3 9.SMB_CLK_RESUME 11.GND 2.+3.3 4.PRST_SIO# 6.LPC_AD2 8.LPC_AD0 10.GND 12.
