User Guide

Configuring the Avaya 1120E IP Deskphone
118
Table 15 on page 118 displays the characteristics of ATA.
Table 15: Summary of ATA characteristics (Part 1 of 3)
Feature Description
Key Events In addition to On hook, Off hook
events, dial pad digit events from the
attached analog device are also
supported. Key press events on the
adapter are sent to the IP Deskphone
through the USB. After the
IP Deskphone receives these events, it
maps them to the corresponding key
events as if the keys on the
IP Deskphone are pressed.
LEDs Not applicable.
Attached Indicator Not applicable.
Back Light Not applicable.
Message Waiting Not applicable.
External Alerter Not applicable.
Incoming Call When there is an incoming call, the
IP Deskphone sends an alerting event
to the adapter. The adapter produces
the ring tones for the attached analog
device to indicate there is an incoming
call on the IP Deskphone.
Caller ID Information Caller ID, if available, is also sent to
the adapter. The adapter sends the
CLID to the attached analog device for
display.
