Additional features

246

2. Press the Up/Down navigation key to

highlight Speed Dial, Call Forward, or

Send IM from the menu.

Note: Presence and Do Not Disturb are

not programmable by using the Copy

key.

Select

3. Press the Select context-sensitive soft

key.

Set

4. Choose one of the following:

— Press the Up/Down navigation key

to highlight the feature key to which

to copy the information to and press

Set.

—Press the Feature key that you want

to use for the service selected.

5. Use the dialpad to enter the label for the

feature key.
