Using your Avaya 1120E IP Deskphone

Connecting the headset (optional)

Perform the following procedure to connect the optional headset to the IP

Deskphone.

1. On the back of the IP Deskphone, plug the headset connector into the

RJ-9 headset jack marked with the ) symbol.

2. Thread the headset cord, along with the handset cord, through the

channels in the stand so that the headset cord exits the channel

marked with the ) symbol.

Selecting the headset tuning parameter

You can select a headset from the following list of supported headsets.

• Type 1: Monaural and Binaural Headset

— Monaural Headset: Plantronics Model number: H251N (Part

number: 64338-01) with cable Model Number: A10 (Part Number:

66268-02)

— Binaural Headset: Plantronics Model number: H261N (Part

number: 64339-01) with cable Model Number: A10 (Part Number:

66268-02)

• Type 2: Monaural and Binaural Headset

— Monaural Headset: Plantronics Model number: HW251N (Part

number: 75100-06) with cable Model Number: A10 (Part Number:

66268-02)

— Binaural Headset: Plantronics Model number: HW261N (Part

number: 75101-06) with cable Model Number: A10 (Part Number:

66268-02)

• Type 3: Binaural Headset

— Binaural Headset: GN Netcom Model number: GN 4800 (Part

number: 48492-09)

After you select a headset, the corresponding tuning parameters are

applied automatically.
