S-Registers
C-2
Figure C-1. Active and Stored Configuration Data
To look at the contents on just one register, use the command S
mm ? where mm
is the number of the S-register. The data module will return three digits,
representing the decimal value of the specified S-register.
To change the value in any one S-register directly, use the command S
mm = nnn
where mm is the number of the S-register and nnn is the number you wish to
place in the register. The following dialog illustrates the use of the S command
to read and change the value contained in an S-register:
ATS18?
055
OK
ATS18=120
OK
ACTIVE PROFILE:
B1 E1 L2 M1 Q0 V1 X4 Y0 &C0 &D0 &G0 &J0 &L0 &P0 & Q0 &R0 &S0 &X0 &Y0
S00:000 S01:000 S02:043 S03:013 S04:010 S05:008 S06:002 S07:060
S08:002 S09:006 S10:014 S12:050 S14:AAH S16:00H S18:000 S21:00H
S22:76H S23:0BH S24:00H S25:005 S26:001 S27:40H
STORED PROFILE 0:
B1 E1 L2 M1 Q0 V1 X1 Y0 &C0 &D0 &G0 &J0 &L0 &P0 &Q0 &R0 &S0 &X0
S00:000 S14:AAH S18:000 S21:00H S22:46H S23:0BH S24:00H S25:005
S26:001 S27:40H
STORED PROFILE 1:
B1 E1 L2 M1 Q0 V1 X4 Y0 &C0 &D0 &G0 &J0 &L0 &P0 &Q0 &R0 &S0 &X0
S00:000 S14:AAH S18:000 S21:00H S22:46H S23:0BH S24:00H S25:005
S26:001 S27:40H
TELEPHONE NUMBERS:
&Z0= 34017
&Z1= 95551212
&Z2= 74802
&Z3= PARIS
OK
ENTER
ENTER
