S-Registers
C-29
Comments: 1. Hayes compatible modems use only bits, 0, 1, and
2 for speeds up to 2400 bps. The 8400B Plus Data
Module uses bit 3 to support speeds above 2400
bps.
2. Bits 6 and 7 are set by the appropriate command,
but there will be no other effect.
3. Refer to the explanation of hexadecimal values
under the “Range of Values” heading on page C-4
.
See Also: "AT Command Line Prefix" on page 3-2, the &T
command on page A-26, and Appendix D for
information about performing remote loopback tests.
Table C-1. Labels Used in S-Registers
Label Description
