S-Registers
C-34
Range of Values: Value may be 00 through FF hexadecimal;
factory-default settings produce a value of 40
hexadecimal.
Storable: yes
Comments: In the 8400B Plus Data Module, bits 2, 4, 5, and 6 will
be set by the appropriate commands. However, there
will be no other effect. Bits 0, 1, and 3 will always be 0.
See Also: none
Table C-1. Labels Used in S-Registers
Label Description
