8400B Plus Data Module User’s Guide
555-020-709
Issue 2
November 1996
Quick-Reference Summaries
E-10
Table E-6. M9/F25 Adapter Pin Assignments
Pin Circuit
Common
Name Direction Lead Name
1CF RLSD
or
DCD
from 8400B Plus Data
Module
Received Line Signal
Detector
or
Data
Carrier Detector
2 BB RD from 8400B Plus Data
Module
Received Data
3 BA SD to 8400B Plus Data
Module
Transmitted Data
4 CD DTR to 8400B Plus Data
Module
DTE Ready
5 AB SG common Signal Ground
6 CC DSR from 8400B Plus Data
Module
DCE Ready
7 CA RTS to 8400B Plus Data
Module
Request To Send
8 CB CTS from 8400B Plus Data
Module
Clear To Send
9 CE RI from 8400B Plus Data
Module
Ring Indicator
