8400B Plus Data Module User’s Guide
555-020-709
Issue 2
November 1996
Installation
2-5
Selecting the Correct Installation Procedure
Figure 2-2. Typical Installation of the US Configuration, including
Telephone and Separate Power Supply
PHONE
LINE/
POWER
!
USE ONLY WITH COMMUNICATION
CIRCUIT POWER SOURCE
(use only with 25-pin
(Rear Endplate)
EIA-232-D
D8W
M9/F25 Adapter
8400B Plus Data Module
EIA-232-D Connector Cord)
(9-pin or 25-pin)
Connector Cord
Wall
D8W
D6AP
AC
Outlet
400B2
Adapter
KS-22911, L2
Jack
Power Supply
Telephone
(Optional)
