Tutorial: Configuring a Bay Networks Router
117383-D Rev 00
4-3
• Serial interface in slot 5
• Dual token ring interface in slot 9
• FDDI interface in slot 11
Figure 4-1. Sample BCC Configuration (BCN Router)
After you create a diagram of the device configuration tree, configure the device
using a cycle of BCC configuration commands similar to those shown in
Figure 4-2
.
ip snmp
telnet
ftp
tftp
community “public”
manager 0.0.0.0
server
ip
riparp
riparp
box
Global Services
serial/5/1
ethernet/13/1
ethernet/13/2
ethernet/13/3
ethernet/13/4
token-ring/9/1
token-ring/9/2
fddi/11/1
