135
Reference for the Business Policy Switch 2000 Command Line Interface
Chapter 4
Spanning Tree, MLT, and Port-Mirroring
This chapter describes how to configure the Spanning Tree Protocol, spanning
tree groups, Multi-Link Trunking (MLT), and port-mirroring. This chapter covers
the following topics:
• “Using spanning tree,” next
• “Using MLT” on page 148
• “Using port-mirroring” on page 151
Refer to the Using the Business Policy Switch 2000 Software Version 2.0 for more
information on multiple spanning tree groups, spanning tree, MLT, and
port-mirroring, as well as configuration directions using the console interface (CI)
menus. Refer to Using Web-based Management for the Business Policy Switch
2000 Software Version 2.0 for information on configuring these features using the
Web-based management system, and refer to Reference for the Business Policy
Switch 2000 Management Software Version 2.0 for configuration information for
the DM.
Using spanning tree
Note: For detailed information on spanning tree parameters, spanning
tree groups, and configuration guidelines, refer to Using the Business
Policy Switch 2000 Software Version 2.0.
