Chapter 4 Spanning Tree, MLT, and Port-Mirroring 149
Reference for the Business Policy Switch 2000 Command Line Interface
The show mlt command is in the privExec command mode.
Table 84 describes the parameters and variables for the
show mlt command.
Figure 30 displays sample output from the
show mlt command.
Figure 30 show mlt command output
mlt command
The mlt command configures a Multi-Link Trunk (MLT). The syntax for the mlt
command is:
mlt <id> [name <trunkname>] [enable|disable] [member
<portlist>]
The mlt command is in the config command mode.
Table 85 describes the parameters and variables for the
mlt command.
Table 84 show mlt command parameters and variables
Parameters and
variables
Description
utilization <1-6> Displays the utilization of the specified enabled MLT(s) in
percentages.
BPS2000#show mlt
Trunk Name Members STP Learning Mode Status
----- ----------- ------------------- --------------------
1 Trunk #1 Normal Basic Disabled
2 Trunk #2 Normal Basic Disabled
3 Trunk #3 Normal Basic Disabled
4 Trunk #4 Normal Basic Disabled
5 Trunk #5 Normal Basic Disabled
6 Trunk #6 Normal Basic Disabled
BPS2000#
