Chapter 4 Spanning Tree, MLT, and Port-Mirroring 153
Reference for the Business Policy Switch 2000 Command Line Interface
no port-mirroring command
The no port-mirroring command disables port-mirroring. The syntax of the
no port-mirroring command is:
no port-mirroring
The no port-mirroring command is in the config command mode.
The
no port-mirroring command has no parameters or variables.
portlist Enter the port numbers.
Xrx Mirror packets received on port X.
Xtx Mirror packets transmitted on port X.
XrxOrXtx Mirror packets received or transmitted on port X.
XrxYtx Mirror packets received on port X and transmitted on port Y.
Note: Do not use this mode for mirroring broadcast and multicast traffic.
XrxYtxOrXtxYrx Mirror packets received on port X and transmitted on port Y or packets received on
port Y and transmitted on port X.
Note: Do not use this mode for mirroring broadcast and multicast traffic.
macaddr Enter the MAC address in format H.H.H.
Asrc Mirror packets with source MAC address A.
Adst Mirror packets with destination MAC address A.
AsrcOrAdst Mirror packets with source or destination MAC address A.
AsrcBdst Mirror packets with source MAC address A and destination MAC address B.
AsrcBdstOrBsrcAdst Mirror packets with source MAC address A and destination MAC address B or
packets with source MAC address B and destination MAC address A.
Table 87 port-mirroring command parameters and variables (continued)
Parameters and
variables
Description
