155
Reference for the Business Policy Switch 2000 Command Line Interface
Chapter 5
VLANs and IGMP
This chapter describes how to configure virtual LANs and IGMP snooping
parameters. This chapter covers the following topics:
• “Increased VLAN support,” next
• “Configuring and displaying VLANs” on page 156
• “Displaying multicast membership” on page 168
• “Using IGMP snooping” on page 170
Refer to the Using the Business Policy Switch 2000 Software Version 2.0 for more
information on VLANs, IGMP snooping, and multicast groups, as well as
configuration directions using the console interface (CI) menus. Refer to Using
Web-based Management for the Business Policy Switch 2000 Software Version 2.0
for information on configuring these features using the Web-based management
system, and refer to Reference for the Business Policy Switch 2000 Management
Software Version 2.0 for configuration information for the DM.
Increased VLAN support
With software version 1.2, the BPS 2000 supports up to 256 VLANs. You can
configure as many as 255 protocol-based VLANs, with up to 14 different
protocols. To find out which version of the BPS 2000 software is running, use the
show sys-info command in the privExec command mode The software
currently running is displayed in the sysDescr field.
You can use 256 port-, protocol-, and MAC SA-based VLANs for the stack with a
Pure BPS 2000 stack running software version 1.2. (The maximum number of
MAC SA-based VLANs available is 48). If you are working with a mixed, or
hybrid, stack, you can use 64 VLANs for the entire stack. When you change from
a Pure BPS 2000 Stack mode to a Hybrid Stack mode:
