Chapter 6 Policy-enabled networks and QoS 181
Reference for the Business Policy Switch 2000 Command Line Interface
Figure 46 show qos actions command output
Figure 47 displays sample output from the show qos meters command.
Beginning with software version 2.0, each service class has a default meter that
uses default actions and mappings.
Figure 47 show qos meters command output
Figure 48 displays sample output from the show qos shapers command.
BPS2000#show qos actions
Id Name Drop Update Set Drop 802.1p Priority
DSCP Precedence
_____ ________________ _____ ______ __________________ _______________
65526 Drop_Traffic True Ignore Ignore Ignore
65527 Standard_Service False 0x0 Not Loss Sensitive Priority 0
65528 Bronze_Service False 0xA Loss Sensitive Priority 2
65529 Silver_Service False 0x12 Loss Sensitive Priority 3
65530 Gold_Service False 0x1A Loss Sensitive Priority 4
65531 Platinum_Service False 0x22 Loss Sensitive Priority 5
65532 Premium_Service False 0x2E Loss Sensitive Priority 6
65533 Network_Service False 0x30 Loss Sensitive Priority 7
65534 Trusted_IP False Ignore Use Egress Map Use Egress Map
65535 Trusted_NonIP False Ignore Ignore Ignore
BPS2000 SW 2.0 in SC2-02 LAB#show qos meters
Id Name Data Commit Commit In-Profile Out-Profile
Spec Rate Burst Action Action
(Kbps)(Bytes)
_____ ________________ ________ ______ __ ________________ ____
1 practice Metered 3000 2047
65526 Drop_Traffic No Meter 0 0 Drop_Traffic
65527 Standard_Service No Meter 0 0 Standard_Servic
65529 Bronze_Service No Meter 0 0 Bronze_Service
65530 Silver_Service No Meter 0 0 Silver_Service
65531 Gold_Service No Meter 0 0 Gold_Service
65532 Platinum_Service No Meter 0 0 Platinum_Servic
65533 Premium_Service No Meter 0 0 Premium_Service
65534 Network_Service No Meter 0 0 Network_Service
