Chapter 6 Policy-enabled networks and QoS 185
Reference for the Business Policy Switch 2000 Command Line Interface
Figure 53 displays sample output from the show qos statistics command.
Figure 53 show qos statistics command output
Resetting
You can reset the system to the factory defaults.
qosagent reset-default command
The qosagent reset-default command deletes all installed states and resets
the system to factory default values. The syntax for the
qosagent
reset-default
command is:
qosagent reset-default
The qosagent reset-default command is in the config mode.
The
qosagent reset-default command has no parameters or variables.
BPS2000#show qos statistics
Id Name Packet Overflow Total Total InProfile
Hits Packet Octets Overflow Octets
Hits Octets
___ _________ ______ __________ __________ __________ __________
1 wizardIP 0 0 0 0 0
2 wizardL2 0 0 0 0 0
Id Name Overflow OutProfile Overflow Shaping Overflow
InProfile Octets OutProfile Q Drops Shaping
Octets Octets Q Drops
_________ __________ __________ __________ __________ __________
1 wizardIP 0 0 0 0 0
2 wizardL2 0 0 0 0 0
