Chapter 6 Policy-enabled networks and QoS 189
Reference for the Business Policy Switch 2000 Command Line Interface
Figure 56 show cops stats command output (1 of 2)
BPS2000#show cops stats
---------------------------------------------
PDP IPv4 Address: 47.130.100.42
TCP Port: 3288
Configuration Source: Static
Authentication Type: None
Last Connection Attempt: 5745
TCP Connect Attempts: 12
TCP Connect Failures: 12
Connection State: Invalid
Keep-Alive Time: 0
Accounting Time: 0
Messages Received: 0
Messages Sent: 0
Messages Syntax Errors: 0
Last Protocol Error: <unknown>
Open Attempts: 0
Open Failures: 0
Unsupported Client Types: 0
Unsupported Versions: 0
Length Mismatches: 0
Unknown Opcodes: 0
Unknown C-NUMs: 0
Bad C-TYPEs: 0
Bad Sends: 0
Wrong Objects: 0
Wrong Opcodes: 0
Client Keep-Alive Timeouts: 0
Authentication Failures: 0
Authentication Missings: 0
---------------------------------------------
PDP IPv4 Address: 47.130.101.81
TCP Port: 3288
Configuration Source: Static
Authentication Type: None
Last Connection Attempt: 6343
TCP Connect Attempts: 12
TCP Connect Failures: 11
Connection State: Connected
Keep-Alive Time: 120
Accounting Time: 0
