198 Chapter 6 Policy-enabled networks and QoS
212160-B
qos queue-set-assignment command
The qos queue-set-assignment command associates the 802.1p priority
values with a specific queue within a specific queue set. This association
determines the egress scheduling treatment that traffic with a specific 802.1p
priority value receives. The syntax for the
qos queue-set-assignment
command is:
qos queue-set-assignment queue-set <setid> 1p <ieee1p>
queue <qid>
The qos queue-set-assignment command is in the config command mode.
Table 115 describes the parameters and variables for the
qos
queue-set-assignment
command.
Configuring QoS filters and filter groups
You can configure filters and filter sets using the CLI. This section covers:
• “qos ip-filter command,” next
• “qos ip-filter-set command” on page 200
• “qos l2-filter command” on page 201
• “qos l2-filter-set command” on page 203
Table 115 qos queue-set-assignment command parameters and variables
Parameters
and variables
Description
queue-set
<setid>
Enter the queue set ID.
1p <ieee1p> Enter the 802.1p priority value for which the queue association is
being modified; range is between 0 and 7.
queue <qid> Enter the queue within the identified queue set to assign the 802.1p
priority traffic at egress.
