qos l2-filter-set command
The qos l2-filter-set command adds and deletes Layer 2 filters into an L2
filter set. The syntax for the
qos l2-filter-set command is:
qos l2-filter-set <fgid> {create set <setid> [name
<setname>] filter <fid> filter-prec <prec>|delete}
The qos l2-filter-set command is in the config command mode.
Table 119 describes the parameters and variables for the
qos l2-filter-set
command.
Table 119 qos l2-filter-set command parameters and variables
Parameters
and variables
Description
<fgid> Enter an integer to specify the filter group ID you want to work with;
range is 1 to 65535.
create set
<setid>
Initiates creation of an L2 filter set with the designated filter set ID.
Enter the IP filter set ID; range is 1 to 65535.
name
<setname>
Assigns a name to the designated filter set ID. Enter the name for the
filter set; maximum is 16 alphanumeric characters.
filter <fid> Adds an L2 filter to the filter set; range is 1 to 65535.
filter-prec
<prec>
Specifies the precedence, or filter evaluation order, within the set.
Enter the precedence value you want for this filter; range is 1 to
65535.
delete Deletes the L2 filter set.
Note: You must define the filter before adding it to a filter set. You
cannot delete an L2 filter set that is referenced in an installed policy. You
cannot delete the last L2 filter in an L2 filter set that is referenced in an
installed policy.
