206 Chapter 6 Policy-enabled networks and QoS
212160-B
The qos meter command is in the config command mode.
Table 121 describes the parameters and variables for the
qos meter command.
Configuring QoS shapers
Table 121 qos meter command parameters and variables
Parameters and variables Description
<metid> Enter an integer to specify the QoS meter; range is 1 to 65535.
name <metname> Assigns a name to the QoS meter with the designated meter ID. Enter name
for meter; maximum is 16 alphanumeric characters.
committed-rate <rate> Specifies rate that traffic must not exceed for extended periods to be
considered in-profile. Enter the rate in Kb/s for in-profile traffic; range is 1 to
65535 Kb/s.
max-burst-rate <burstrate> Specifies the largest burst of traffic that can be received a given time for the
traffic to be considered in-profile. Used in calculating the committed burst
size. Enter the burst size in Kb/s for in-profile traffic; range is 1 to 65535
Kb/s
max-burst-duration
<burstdur>
Specifies the amount of time that the largest burst of traffic that can be
received for the traffic to be considered in-profile. Used in calculating the
committed burst size. Enter the burst duration in ms for in-profile traffic;
range is 1 to 65535 ms.
delete Deletes the specified meter.
You cannot delete a meter that is referenced in an installed policy.
Note: You must be using either the BPS2000-1GT, BPS2000-2GT, or
BPS2000-2GE MDA in order to implement the QoS shaping features.
