208 Chapter 6 Policy-enabled networks and QoS
212160-B
Gathering QoS statistics
You can gather statistics on QoS, such as the number of in-profile octets and
out-of-profile octets. These statistics can serve as an important method to evaluate
the effectiveness of the installed policies. However, tracking these statistics
requires additional system resources, which limits the number of filters for
classification.
qosagent police-statistics command
The qosagent police-statistics command gathers traffic policing, or
metering, statistics. The syntax for the
qosagent police-statistics
command is:
qosagent police-statistics {enable|disable}
The qosagent police-statistics command is in the config command
mode.
Table 123 describes the parameters and variables for the
qosagent
police-statistics
command.
You cannot delete a shaper that is referenced in an installed policy.
Table 123 qosagent police-statistics command parameters and variables
Parameters and
variables
Description
enable|disable Set policing statistics to:
• Enable—statistics are tracked by default for all policies defined
after this command is issued
• Disable—disables tracking statistics for policies defined after this
command is issued
